基于數字預失真的發射機I/Q不平衡矯正

陳雷; 岳光榮; 唐俊林; 李少謙; 宋志群; 曾媛

doi:10.11999/JEIT160581

基于數字預失真的發射機I/Q不平衡矯正

doi: 10.11999/JEIT160581

2.
(電子科技大學通信抗干擾國家級重點實驗室成都 611731) ②(中國電子科技公司第54研究所通信網信息傳輸與分發技術重點實驗室石家莊 050081) ③(上海宇航系統工程研究所上海 201108)

基金項目:

國家科技重大專項課題(2013ZX03005010)，通信網信息傳輸與分發技術重點實驗室開放課題(KX152600016/ITD- U15007)，國家自然科學基金(61371103, 61401447)

計量
- 文章訪問數: 1688
- HTML全文瀏覽量: 259
- PDF下載量: 408
- 被引次數: 0
出版歷程
- 收稿日期: 2016-06-03
- 修回日期: 2016-12-13
- 刊出日期: 2017-04-19

Calibration of Transmitter I/Q Imbalance Based on Digital Pre-distortion

2.
(National Key Laboratory of Science and Technology on Communications, University of Electronic Science and Technology of China, Chengdu 611731, China)

Funds:

The National Science and Technology Major Project (2013ZX03005010), ITDCN Open Program (KX152600016 /ITD-U15007), The National Natural Science Foundation of China (61371103, 61401447)

摘要

摘要: 同相支路(I路)與正交支路(Q路)不平衡、載波泄漏以及帶內失真會造成系統性能損失，尤其是在采用直接變頻結構的發射機中。該文提出一種自適應I/Q不平衡矯正方案，針對發射機中存在的與頻率相關的I/Q不平衡、載波泄漏以及帶內失真進行矯正。該文方案直接估計I/Q兩支路的反濾波器，避免了先求響應再求逆響應的額外運算，降低了運算復雜度。同時，該文還提出一種基于迭代的在線追蹤方案，用于跟蹤由于發射機溫度變化造成的I/Q不平衡的參數漂移現象。經過復雜度分析，該文提出的方案擁有很高的補償效率。最后，仿真結果驗證了兩種方案針對各類射頻損傷矯正的有效性。
- 無線通信 /
- 發射機矯正 /
- 射頻損傷
Abstract: The in-phase (I) and quadrature (Q) imbalance, carrier leakage and in-band distortion may lead to severe performance degradation, especially in direct-conversion radio architecture. An adaptive pre-distortion scheme is proposed to calibrate I/Q imbalance, carrier leakage and in-band distortion. In the proposed scheme, the inverse filter of each branch is estimated directly which avoids redundant computation. Moreover, an iterative scheme is proposed to track the parameters variation due to temperature in an online manner. By complexity analysis, the proposed scheme is efficient. The effectiveness of the scheme is testified by simulation.
- Wireless communications /
- Transmitter calibration /
- RF impairments
