多路延遲正交合成的多徑信道射頻干擾對消

劉建成; 全厚德; 李召瑞; 劉東林; 趙宏志

doi:10.11999/JEIT160521

多路延遲正交合成的多徑信道射頻干擾對消

doi: 10.11999/JEIT160521

1.
(軍械工程學院信息工程系石家莊 050003) ②(電子科技大學通信抗干擾技術國家級重點實驗室成都 611731)

基金項目:

國家自然科學基金(61531009, 61501093, 61271164, 61471108)

計量
- 文章訪問數: 1461
- HTML全文瀏覽量: 249
- PDF下載量: 342
- 被引次數: 0
出版歷程
- 收稿日期: 2016-05-23
- 修回日期: 2016-10-09
- 刊出日期: 2017-03-19

RF Interference Cancellation Based on Multi-tap Delay and Orthogonal Combination in Multipath Channel

1.
(Department of Information Engineering, Ordnance Engineering College, Shijiazhuang 050003, China)
2.
(National Key Laboratory of Science and Technology on Communications, University of Electronic Science and Technology of China, Chengdu 611731, China)

Funds:

The National Natural Science Foundation of China (61531009, 61501093, 61271164, 61471108)

摘要

摘要: 該文針對單路延遲對消系統不能有效解決多徑信道的超短波無線電臺共址干擾消除問題，給出了等間隔多路延遲正交合成的射頻干擾對消方案，進而提出了新的衰減系數求解方法。在設定時間延遲范圍和參考信號路數基礎上，該方法通過迭代加權實時有效估計多路參考信號的相關矩陣，接收信號與參考信號的相關向量，進而求解維納霍夫方程得到各路衰減系數，有效抑制多徑信道的自干擾，克服了已有方法需同時調節幅度和相位，以及相關向量和相關矩陣估計精度低的不足。另外，理論分析了衰減系數的求解過程，并推導了自干擾對消比的閉合表達式。分析和仿真結果表明，該方法在一定延遲誤差情況下，可獲得90 dB以上的對消比，比已有方法提高了約9 dB，有效解決了多徑信道的射頻干擾對消問題。
- 共址干擾 /
- 射頻自干擾對消 /
- 多徑信道 /
- 對消比
Abstract: The one delay tap cancellation system is weakly to suppress the co-site interference between the Very High Frequency (VHF) radios in multipath channel. To overcome this obstacle, a Radio Frequency (RF) interference cancellation scheme based on the multi-tap delay and orthogonal combination is presented, as well as a new solving attenuation coefficients method. Considering the fixed delay scale and the number of taps, this method accurately estimates the reference signal autocorrelation matrix and the cross-correlation vector between reference signals and received signal on the basis of instantaneous and iterative weighted averaging. The attenuation coefficients are achieved by solving Wiener-Hopf equation via the estimated autocorrelation matrix and cross-correlation vector. Compared with the existing approaches, this method does not need to adjust and control the amplitudes as well as the phases of reference signals simultaneously, and it improves the accuracy of estimating cross-correlation vector and autocorrelation matrix. In addition, the closed-form expression of self-interference cancellation ratio is derived through theoretically analyzing the attenuation coefficients solution. The analysis and simulation results show that the proposed method could obtain self-interference cancellation ratio of more than 90 dB, which is about 9 dB higher than the existing method. This study is significant for eliminating RF self-interference in multipath channel.
- Co-site interference /
- RF interference cancellation /
- Multipath channel /
- Cancellation ratio

HTML全文

參考文獻(22)

LI Wenlu, ZHAO Zhihua, TANG Jian, et al. Performance analysis and optimal design of the adaptive interference cancellation system[J]. IEEE Transactions on Electromagnetic Compatibility, 2013, 55(6): 1068-1075. doi: 10.1109/TEMC.2013.2265803.

WIKLUNDH K, FORS K, and HOLM P. The risk of coexistence problems between DAB and DVB-T2 and military services at the 225-240 MHz band[C]. 2015 IEEE International Symposium on Electromagnetic Compatibility (EMC), Dresden, Germany, 2015: 183-188. doi: 10.1109/ISEMC. 2015.7256155.

ZHANG Zhongshan, CHAI Xiaomeng, LONG Keping, et al. Full duplex techniques for 5G networks: Self-interference cancellation, protocol design, and relay selection[J]. IEEE Communications Magazine, 2015, 53(5): 128-137. doi: 10. 1109/MCOM.2015.7105651.

ZHOU Ping, LU Yinghua, TAO Yong, et al. Simulation analysis on co-site interference of vehicular digital communication system based on IM prediction method by BER[J]. The Journal of China Universities of Posts and Telecommunications, 2016, 23(1): 31-41. doi: 10.1016/S1005- 8885(16)60005-5.

LAUGHLIN L, BEACH M A, MORRIS K A, et al. Electrical balance duplexing for small form factor realization of in-band full duplex[J]. IEEE Communications Magazine, 2015, 53(5): 102-110. doi: 10.1109/MCOM.2015.7105648.

DINESH B, EMILY M, and SACHIN K. Full duplex radios[C]. Proceedings of the ACM SIGCOMM 2013 Conference on SIGCOMM, Hong Kong, China, 2013: 375-386. doi: 10.1145/ 2486001.2486033.

ZI Ran, GE Xiaohu, THOMPSON J, et al. Energy efficiency optimization of 5G radio frequency chain systems[J]. IEEE Journal on Selected Areas in Communications, 2016, 34(4): 758-771. doi: 10.1109/JSAC.2016.2544579.

CHOI J I, JAIN M, KANNAN S, et al. Achieving single channel, full-duplex wireless communication[C]. Proceedings of the ACM Sixteenth Annual International Conference on Mobile Computing and Networking, Chicago, IL, USA, 2010: 1-12.

SAMUEL J H and STEPHEN J R. High power HF and noise cancellation system, RADC-TR-80-56 [R]. NewYork: Rome Air Development Center, 1980.

LEE D W and BURTON S A. High power broadband cancellation system, RADC-TR-81-15 [R]. NewYork: Rome Air Development Center, 1981.

馬義廣, 杜武林. 自適應干擾抵消系統的性能分析與設計[J]. 西安電子科技大學學報, 1992, 19(1): 84-92.

MA Yiguang and DU Wulin. Performance analysis and design of adaptive interference cancellation system[J]. Journal of Xidian University, 1992, 19(1): 84-92.

RIIHONEN T and WICHMAN R. Analog and digital self-interference cancellation in full-duplex MIMO-OFDM transceivers with limited resolution in A/D conversion[C]. IEEE Conference Record of the Forty Sixth Asilomar Conference on Signals, Systems and Computers (ASILOMAR), Pacific Grove, CA, USA, 2012: 45-49. doi: 10.1109/ ACSSC.2012.6488955.

HONG S, BRAND J, CHOI J, et al. Applications of self-Interference cancellation in 5G and beyond[J]. IEEE Communications Magazine, 2014, 54(2): 114-121. doi: 10.1109/MCOM.2014.6736751.

PAN Yulong, ZHOU Cheng, CUI Gaofeng, et al. Self- interference cancellation with RF impairments suppression for full-duplex systems[C]. 2015 IEEE 82nd Vehicular Technology Conference (VTC Fall), Boston, MA, USA, 2015: 1-5. doi: 10.1109/VTCFall.2015.7391136.

DEBAILLIE B, BROEK D J, LAVIN C, et al. Analog/RF solutions enabling compact full-duplex radios[J]. IEEE Journal on Selected Areas in Communications, 2014, 32(9): 1662-1673. doi: 10.1109/JSAC.2014.2330171.

JOSEPH G M and KENNETH E K. Optimal tuning of analog self-interference cancellers for full-duplex wireless communication[C]. Proceedings of the 50th Annual Allerton Conference on Communication, Control, and Computing (Allerton), Monticello, IL, USA, 2012: 246-251. doi: 10.1109/Allerton. 2012.6483225.

CHOI Y S and HOOMAN S M. Simultaneous transmission and reception: Algorithm, design and system level performance[J]. IEEE Transactions on Communications on Wireless Communications, 2013, 12(12): 5992-6010. doi: 10.1109/TWC.2013.101713.121152.

KENNETH E K, JOSEPH G M, and PERRY B T. Multi-tap RF canceller for in-band full-duplex wireless communications[J]. IEEE Transactions on Wireless Communications, 2016, 15(6): 4321-4334. doi: 10.1109/TWC. 2016.2539169.

吳飛, 馬萬治, 邵士海, 等. 多抽頭延遲設置與幅相誤差對全雙工射頻自干擾消除的影響[J]. 電子與信息學報, 2015, 37(7): 1538-1543. doi: 10.11999/JEIT141275.

WU Fei, MA Wanzhi, SHAO Shihai, et al. Impact of delay setting, amplitude and phase errors on multi-tap self- interference cancellation in full-duplex system[J]. Journal of Electronics Information Technology, 2015, 37(7): 1538-1543. doi: 10.11999/JEIT141275.

HAYKIN S S. Adaptive Filter Theory[M]. 5th ed, Englewood Cliff: Prentice Hall Press, 2008: 440-465.
