基于圓柱繞流直徑壓強差的二維風測量方法

劉成; 趙湛; 杜利東; 方震

doi:10.11999/JEIT160468

基于圓柱繞流直徑壓強差的二維風測量方法

doi: 10.11999/JEIT160468

2.
(中國科學院電子學研究所北京 100190) ②(中國科學院大學北京 100049)

基金項目:

公益行業專項（GYHY201006044），國家自然科學基金(51305423)

計量
- 文章訪問數: 1145
- HTML全文瀏覽量: 109
- PDF下載量: 342
- 被引次數: 0
出版歷程
- 收稿日期: 2016-05-09
- 修回日期: 2016-09-23
- 刊出日期: 2017-03-19

Method of Measuring Two-dimensional Wind Based on Diametrical Pressure Differences Developed by Flow Around Cylinder

2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

Special Fund for Public Welfare (GYHY- 201006044), The National Natural Science Foundation of China (51305423)

摘要

摘要: 基于流量傳感器的圓柱結構2維風傳感器，其測量性能對地面風測量而言不夠準確。由此，該文通過分析風洞實驗數據，建立一種數學模型來描述圓柱繞流中直徑兩端壓強差的分布，并根據該模型提出一種通過檢測該直徑壓強差來計算風速風向的2維風測量方法。對風洞測試數據應用該方法，在2~40 m/s風速范圍內，風速計算值誤差不超過(0.2+0.03 V) m/s，風向計算值誤差不超過5。相比使用流量傳感器的圓柱結構2維風傳感器，該方法提高了測量準確度。同時，該方法不需要轉動部件，不受機械摩擦和慣性的制約，需要占用的空間小。
- 2維風測量 /
- 圓柱繞流 /
- 直徑壓強差 /
- 風速風向
Abstract: The cylindrical two-dimensional wind sensor employing flow meters is not accurate enough for surface wind measurement. By analyzing the data from wind tunnel experiments, a model is proposed to describe the diametrical pressure differences developed by the flow around a circular cylinder. A method is derived from the model for two-dimensional wind measurement by detecting the diametrical pressure differences. When the proposed method is applied to the data from wind tunnel tests in range of 2~40 m/s, the relative wind speed errors and the wind direction errors are no more than (0.2+0.03 V) m/s and 5 respectively. The proposed method is more accurate than the cylindrical two-dimensional wind sensor using flow meters. Without moving parts, the method is immune to mechanical wear and inertia.
- Two-dimensional wind measurement /
- Flow around a cylinder /
- Diametrical pressure difference /
- Wind speed and direction

HTML全文

參考文獻(22)

孫學金, 王曉蕾, 李浩, 等. 大氣探測學[M]. 北京: 氣象出版社, 2009: 172-247.

SUN Xuejin, WANG Xiaolei, LI Hao, et al. Atmospheric Observation[M]. Beijing: China Meteorological Press, 2009: 172247.

BRUSCHI P, DEI M, and PIOTTO M. A low-power 2-D wind sensor based on integrated flow meters[J]. IEEE Sensors Journal, 2009, 9(12): 16881696. doi: 10.1109/JSEN.2009. 2030652.

ZHU Yanqing, CHEN Bei, QIN Ming, et al. 2-D micromachined thermal wind sensorsA review[J]. IEEE Internet of Things Journal, 2014, 1(3): 216232. doi: 10.1109/ JIOT.2014.2319296.

VERESHCHAGINA E, TIGGELAAR R M, SANDERS R G P, et al. Low power micro-calorimetric sensors for analysis of gaseous samples[J]. Sensors and Actuators B: Chemical, 2015, 206: 772787. doi: 10.1016/j.snb.2014.08.077.

LIU Haobing, LIN Nay, PAN Shanshan, et al. High sensitivity, miniature, full 2-D anemometer based on MEMS hot-film sensors[J]. IEEE Sensors Journal, 2013, 13(5): 19141920. doi: 10.1109/JSEN.2012.2236014.

KOWALSKI L, JIMENEZ V, DOMINGUEZ-PUMAR M, et al. Low pressure spherical thermal anemometer for space missions[C]. 2013 IEEE Sensors, Baltimore, Maryland, USA, 2013: 14. doi: 10.1109/ICSENS.2013.6688493.

KOWALSKI L, ATIENZA M T, GORRETA S, et al. Spherical wind sensor for the atmosphere of Mars[J]. IEEE Sensors Journal, 2016, 16(7): 18871897. doi: 10.1109/JSEN. 2015.2509168.

DONG Ziqiang, CHEN Jingjing, QIN Yukun, et al. Fabrication of a micromachined two-dimensional wind sensor by Au-Au wafer bonding technology[J]. Journal of Microelectromechanical Systems, 2012, 21(2): 467475. doi: 10.1109/JMEMS.2011.2179014.

ZHU Yanqing, CHEN Bei, GAO Di, et al. A robust and low-power 2-D thermal wind sensor based on a glass-in-silicon reflow process[J]. Microsystem Technologies, 2015, 22(1): 151162. doi: 10.1007/s00542-015-2423-9.

GEORGIOU D P and KYPROS F M. Fabrication and calibration of a sub-miniature 5-hole probe with embedded pressure sensors for use in extremely confined and complex flow areas in turbomachinery research facilities[J]. Flow Measurement and Instrumentation, 2014, 39: 5463. doi: 10.1016/j.flowmeasinst.2014.07.005.

PIOTTO M, DEI M, PENNELLI G, et al. A miniaturized 2D solid state anemometer based on thermal flow sensors[J]. Procedia Chemistry, 2009, 1(1): 14631466. doi: 10.1016/j. proche.2009.07.365.

PIOTTO M, PENNELLI G, and BRUSCHI P. Fabrication and characterization of a directional anemometer based on a single chip MEMS flow sensor[J]. Microelectronic Engineering, 2011, 88(8): 22142217. doi: 10.1016/j.mee.2010.11.009.

張兆順, 崔桂香. 流體力學[M]. 北京: 清華大學出版社, 1999: 167168.

ZHANG Zhaoshun and CUI Guixiang. Hydromechanics[M]. Beijing: Tsinghua University Press, 1999: 167168.

SCHLICHTING H. Boundary-Layer Theory[M]. 7th Edition, New York: McGraw-Hill, 1979: 1223.

ZURELL Cory. Aerodynamics of a circular cylinder inclined to airflow and wind-induced vibrations of dry, inclined cables at high wind speeds[D]. [Ph.D. dissertation], University of Ottawa, 2004: 2225.

CARE I and ARENAS M. On the impact of anemometer size on the velocity field in a closed wind tunnel[J]. Flow Measurement and Instrumentation, 2015, 44: 210. doi: 10.1016/j.flowmeasinst.2014.11.007.

CHEN Wenli, LI Hui, and HU Hui. An experimental study on a suction flow control method to reduce the unsteadiness of the wind loads acting on a circular cylinder[J]. Experiments in Fluids, 2014, 55(4): 14. doi: 10.1007/s00348-014-1707-7.

LYSENKO D A, ERTESVG I S, and RIAN K E. Large- eddy simulation of the flow over a circular cylinder at Reynolds number 2104[J]. Flow, Turbulence and Combustion, 2014, 92(3): 673698. doi: 10.1007/s10494-013- 9509-1.

GIACOMO P. Equation for the determination of the density of moist air (1981)[J]. Metrologia, 1982, 18(3): 3340. doi: 10.1088/0026-1394/18/3/011.

LIU Cheng, DU Lidong, and ZHAO Zhan. A directional cylindrical anemometer with four sets of differential pressure sensors[J]. Review of Scientific Instruments, 2016, 87(3): 035105. doi: 10.1063/1.4943222.
