基于地磁輔助的室內行人定位航向校正方法

馬明; 宋千; 李楊寰; 谷陽; 周智敏

doi:10.11999/JEIT160407

基于地磁輔助的室內行人定位航向校正方法

doi: 10.11999/JEIT160407

計量
- 文章訪問數: 1609
- HTML全文瀏覽量: 158
- PDF下載量: 508
- 被引次數: 0
出版歷程
- 收稿日期: 2016-04-22
- 修回日期: 2016-11-23
- 刊出日期: 2017-03-19

Magnetic-aided Heading Error Calibration Approach for Indoor Pedestrian Positioning

摘要

摘要: 在基于慣性傳感器的室內人員自主定位系統中，由于陀螺儀存在隨時間增長的漂移，需要依靠地磁場對航向校正。然而，室內場景中地磁場會受到比較嚴重的干擾，磁力計自身也存在一定誤差，嚴重影響了地磁場輔助定位的航向校正效果。該文提出一種地磁輔助的室內定位航向校正方法，該方法首先結合人體運動模型對磁力計進行校準，獲取相關校準系數，提高磁力計解算航向精度。在此基礎上利用改進的磁場準靜態檢測方法提取可用的磁力計觀測量，經校準系數校準后結合零速更新算法(Zero velocity UPdaTe, ZUPT)輔助的擴展卡爾曼濾波(Extended Kalman Filter, EKF)，對陀螺儀航向進行濾波校正。實驗結果顯示在長約684 m的軌跡下航向誤差僅為3.2定位誤差小于0.5 m，定位精度優于0.2%，驗證了該方法較傳統的磁場輔助航向校正方法的優越性。
- 室內行人定位 /
- 磁場準靜態檢測 /
- 航向校正 /
- 磁力計校準
Abstract: In inertial based self-contained pedestrian positioning systems, because the drifts of the gyroscopes grow with time, it relies on the earth magnetic field to suppress the heading errors. However, the earth magnetic field suffers from severe interference in indoor scenarios, and the magnetometer itself has measurement errors, the above reasons have dramatically limited the performance of the magnetometer-aided heading error calibration. This paper proposes a magnetic-aided heading error calibration approach. Firstly, the magnetometer is calibrated according to the motion model of the pedestrian and the calibration coefficients obtained are used to improve the accuracy of heading derived by the magnetometer. On this basis, a proved Quasi-Static magnetic Field (QSF) detection approach is proposed to extract the usable magnetic information fed into Zero velocity UPdaTe (ZUPT)- aided Extended Kalman Filter (EKF) algorithm to conduct the heading calibration. The experiment results show that the 684 meter long walk only has a position error of less than 0.5 meter and heading error of 3.2 degrees, and the position error is less than 0.2% of the total walking distance. The results indicate that the performance of the proposed method is superior to the existing approach.
- Indoor pedestrian positioning /
- Quasi-static magnetic field detector /
- Heading calibration /
- Magnetometer calibration

HTML全文

參考文獻(16)

LI Binghao, GALLAGHER T, DEMPSTER A, et al. How feasible is the use of magnetic field alone for indoor positioning[C]. 2012 International Conference on Indoor Positioning and Indoor Navigation (IPIN), Sydney, Australia, 2012: 1-9. doi: 10.1109/IPIN.2012.6418880.

HIDE C, BOTTERILL T, and ANDREOTTI M. Low cost vision-aided IMU for pedestrian navigation[J]. Global Positioning Systems, 2011, 10: 3-10. doi: 10.1109/UPINLBS. 2010.5653658.

SKOG I, NILSSON J, and HANDEL P. Pedestrian tracking using an IMU array[C]. International Conference on Electronics, Computing and Communication Technologies, Bangalore, India, 2014: 1-4. doi: 10.1109/CONECCT.2014. 6740346.

GU Yang, SONG Qian, LI Yanghuan, et al. Foot-mounted pedestrian navigation based on particle filter with an adaptive weight updating strategy[J]. The Journal of Navigation, 2015, 68(1): 23-38. doi: 10.1017/S037346 3314000496.

REN Mingrong, PAN Kai, LIU Yanhong, et al. A novel pedestrian navigation algorithm for a foot-mounted inertial- sensor-based system[J]. Sensors, 2016, 16(1): 139. doi: 10. 3390/s16010139.

RUPPELT J, KRONENWETTG N, and TROMMER F. A novel finite state machine based step detection technique for pedestrian navigation systems[C]. International Conference on Indoor Positioning and Indoor Navigation (IPIN), Alberta, Canada, 2015: 1-7. doi: 10.1109/IPIN.2015.7346771.

ANGERMANN M and ROBERTSON P. Foot-slam: Pedestrian simultaneous localization and mapping without exteroceptive sensors-hitchhiking on human perception and cognition[J]. Proceedings of the IEEE, 2012, 100: 1840-1848. doi: 10.1109/JPROC.2012. 2189785.

BASIRI A, PELTOLA P, FIGUEIRED P, et al. Indoor positioning technology assessment using analytic hierarchy process for pedestrian navigation services[C]. International Conference on Localization and GNSS, Gothenburg, Sweden, 2015: 1-6. doi: 10.1109/ICL-GNSS.2015.7217157.

GU Yang, MA Ming, LI Yanghuan, et al. Accurate height estimation based on a priori knowledge of buildings[C]. Proceedings of the International Conference on Indoor Positioning and Indoor Navigation (IPIN), Montbeliard, France, 2013: 28-31. doi: 10.1109/IPIN.2013.6817891.

FOXLIN E. Pedestrian tracking with shoe-mounted inertial sensors[J]. Computer Graphics and Applications, 2005, 30(5): 20-26. doi: 10.1109/MCG.2005.140.

NILSSON J, SKOG I, and HANDEL P. A note on the limitations of ZUPTs and the implications on sensor error modeling[C]. Proceedings of the International Conference on Indoor Positioning and Indoor Navigation (IPIN), Sydney, Australia, 2012: 20-22.

JIMENEZ A, SECO F, PRIETO J, et al. Indoor pedestrian navigation using an INS/EKF framework for yaw drift reduction and a foot-mounted IMU[C]. Workshop on Positioning Navigation and Communication, Dresden, Germany, 2010: 135-143. doi: 10.1109/WPNC.2010.5649300.

AFZAL M, RENAUDIN V, and LACHAPELLE G. Use of Earths magnetic field for mitigating gyroscope errors regardless of magnetic perturbation[J]. Sensors, 2011: 11(12): 11390-11414. doi: 10.3390/s111211390.

BUSATO A, PACES P, and POPELKA J. Magnetometer data fusion algorithms performance in indoor navigation: Comparison, calibration and testing[C]. IEEE Metrology for Aerospace, Benevento, Italy, 2014: 388-393. 10.1109/Metro AeroSpace.2014.6865955.

RENAUDIN V, AFZAL M, and LACHAPELLE G. New method for magnetometers based orientation estimation[C]. Position Location and Navigation Symposium, 2010: 348-356. doi: 10.1109/PLANS.2010.5507301.

FENG Wenguang, LIU Shibin, LIU Shiwei, et al. A calibration method of three-axis magnetic sensor based on ellipsoid fitting[J]. Journal of Information Computational Science, 2013, 10(6): 1551-1558. doi: 10.12733/jics20101833.
