一種無線體域網發射機體偏置線性化技術

柳揚; 楊銀堂; 李迪; 石佐辰

doi:10.11999/JEIT160297

一種無線體域網發射機體偏置線性化技術

doi: 10.11999/JEIT160297

柳揚^1, ,,
楊銀堂¹,
李迪¹,
石佐辰¹

基金項目:

國家自然科學基金(61504102)

計量
- 文章訪問數: 1237
- HTML全文瀏覽量: 109
- PDF下載量: 315
- 被引次數: 0
出版歷程
- 收稿日期: 2016-03-31
- 修回日期: 2016-07-28
- 刊出日期: 2017-02-19

Body Biasing Linearization Technique for Wireless Body Area Network Transmitter

Funds:

The National Natural Science Foundation of China (61504102)

摘要

摘要: 該文針對無線體域網人體介質通信(Human Body Communication, HBC)發射機嚴格的輸出頻譜指標，提出一種利用體偏置線性化技術進行頻譜整形的技術。通過設計緩沖器中晶體管體偏置，從而調整晶體管二階非線性系數，最終消除輸出端的二階互調項(Second order InterModulation, IM2)。采用0.35 m CMOS工藝和1.8 V供電電壓設計了一個基于體偏置技術的HBC發射機實例。仿真結果顯示二階輸入截點(IIP2)優化到 90 dBm，輸出頻譜在1 MHz處抑制-130 dBr。較傳統電路，該技術提高了23 dB頻譜抑制，使輸出頻譜符合無線體域網IEEE 802.15.6協議中-120 dBr的指標。
- 無線體域網 /
- 放大器 /
- 線性化 /
- 集成電路
Abstract: A body biasing linearization technique is proposed to shape output spectrum mask to meet the stringent specification of the Human Body Communication (HBC) standard for Wireless Body Area Network (WBAN). Body biasing of the buffer transistors is properly designed, accordingly second-order nonlinearity coefficient is tuned so that Second order InterModulation product (IM2) at the output of buffer is cancelled. Under 0.35 m CMOS process and a supply voltage of 1.8 V, a sample HBC transmitter based on body biasing is designed. Simulation results show that an optimum of 90 dBm IIP2 can be obtained and output transmit spectral mask at 1 MHz is attenuated to be -130 dBr (dB relative to the center frequency). Compared with conventional circuits, an improvement of 23 dB spectrum attenuation is achieved, satisfying the -120 dBr requirement of IEEE 802.15.6 for WBAN.
- Wireless Body Area Network (WBAN) /
- Amplifier /
- Linearization /
- Integrated circuit

HTML全文

參考文獻(16)

鄒衛霞, 康峰源, 杜光龍, 等. 基于中國醫用體域網頻段的物理層方案設計及干擾分析[J]. 電子與信息學報, 2015, 37(2): 429-434. doi: 10.11999/JEIT140901.

ZOU Weixia, KANG Fengyuan, DU Guanglong, et al. Physical layer proposal design and interference analysis based on Chinese medical band in wireless body area network[J]. Journal of Electronics Information Technology, 2015, 37(2): 429-434. doi: 10.11999/JEIT140901.

孫彥贊, 姜玉鳳, 吳雅婷, 等. 基于改進式隨機不完全著色算法的無線體域網干擾協調[J]. 電子與信息學報, 2015, 37(9): 2204-2210. doi: 10.11999/JFIT141621.

SUN Yanzan, JIANG Yufeng, WU Yating, et al. Improved random incomplete coloring for interference mitigation in wireless body area networks[J]. Journal of Electronics Information Technology, 2015, 37(9): 2204-2210. doi: 10. 11999/JFIT141621.

IEEE 802.15.6-2012. IEEE standard for local and metropolitan area networks part 15.6: Wireless body area networks[S]. 2012. doi: 10.1109/IEEESTD.2012.6161600.

LEE H, LEE K, HONG S, et al. A 5.5mW IEEE-802.15.6 wireless body-area-network standard transceiver for multichannel electro-acupuncture application[C]. IEEE International Solid-State Circuits Conference Digest of Technical Papers, San Francisco, 2013: 452-453. doi: 10.1109/ ISSCC.2013.6487811.

LEE H, CHO H, and YOO H J. A 33 W/node duty cycle controlled HBC transceiver system for medical BAN with 64 sensor nodes[C]. IEEE Proceedings of the Custom Integrated Circuits Conference, San Jose, 2014: 1-8. doi: 10.1109/CICC. 2014.6946058.

CHO H, LEE H, BAE J, et al. A 5.2mW IEEE 802.15.6 HBC standard compatible transceiver with power efficient delay-locked-loop based BPSK demodulator[C]. IEEE Asian Solid-State Circuits Conference, KaoHsiung, 2014: 297-300. doi: 10.1109/ASSCC.2014.7008919.

ONIZUKA K, ISHIHARA H, HOSOYA M, et al. A 1.9 GHz CMOS power amplifier with embedded linearizer to compensate AM-PM distortion[J]. IEEE Journal of Solid-State Circuits, 2012, 47(8): 1820-1827. doi: 10.1109/ JSSC.2012.2196629.

HU S, KOUSAI S, and WANG H. A broadband mixed-signal CMOS power amplifier with a hybrid class-G Doherty efficiency enhancement technique[J]. IEEE Journal of Solid-State Circuits, 2016, 51(3): 598-613. doi: 10.1109/JSSC. 2015.2508023.

BA A, CHILLARA V K, LIU Y H, et al. A 2.4GHz class-D power amplifier with conduction angle calibration for -50dBc harmonic emissions[C]. Radio Frequency Integrated Circuits Symposium, Tampa, 2014: 239-242. doi: 10.1109/RFIC.2014. 6851708.

劉潔, 胡波雄, 王剛, 等. 一種適用于Ku波段行波管放大器的預失真線性化器[J]. 電子與信息學報, 2014, 36(10): 2515-2520. doi: 10.3724/SP.J.1146.2013.01820.

LIU Jie, HU Boxiong, WANG Gang, et al. A predistortion linearizer for Ku-band traveling wave tube amplifier[J]. Journal of Electronics Information Technology, 2014, 36(10): 2515-2520. doi: 10.3724/SP.J.1146.2013.01820.

LIU Yang, ZHAO Bo, YANG Yintang, et al. A novel hybrid two-stage IM2 cancelling technique for IEEE 802.15.6 HBC standard[C]. IEEE Biomedical Circuits and Systems Conference, Lausanne, 2014: 640-643. doi: 10.1109/BioCAS. 2014.6981807.

LEE I Y, KIM S, LEE S S, et al. Spur reduction techniques with a switched-capacitor feedback differential PLL and a DLL-based SSCG in UHF RFID transmitter[J]. IEEE Transactions on Microwave Theory and Techniques, 2015, 63(4): 1202-1210. doi: 10.1109/TMTT.2015.2405536.

FRANCOIS B and REYNAERT P. Highly linear fully integrated wideband RF PA for LTE-advanced in 180-nm SOI[J]. IEEE Transactions on Microwave Theory and Techniques, 2015, 63(2): 649-658. doi: 10.1109/TMTT.2014. 2380319.
