基于空頻分解信號子空間向量的時間反演成像

鐘選明; 李軍野; 廖成

doi:10.11999/JEIT160272

基于空頻分解信號子空間向量的時間反演成像

doi: 10.11999/JEIT160272

基金項目:

國家自然科學基金委和中國工程物理研究院聯合基金(U1330109)

計量
- 文章訪問數: 1196
- HTML全文瀏覽量: 128
- PDF下載量: 481
- 被引次數: 0
出版歷程
- 收稿日期: 2016-03-21
- 修回日期: 2016-08-17
- 刊出日期: 2017-02-19

Time Reversal Imaging Algorithm Based on Signal-subspaceVectors from the Spatial-frequency Decomposition

Funds:

The United Fund of National Natural Science Foundation of China and China Academy of Engineering Physics (U1330109)

摘要

摘要: 論文提出基于空頻分解信號子空間向量的時間反演成像新方法。利用天線陣列采集的散射場數據建立空頻矩陣，奇異值分解該矩陣得到信號子空間向量，以此實現對目標的選擇性成像?；谕耆⑸鋱?chǎng)數據的成像偽譜包含多個子向量貢獻，相當于多次成像疊加，具有統計特性。新方法既避免了傳統的空空分解時間反演算法產生的隨機相位的影響，又具有較好的抗干擾性能，即使疊加信噪比10 dB的高斯白噪聲，也能實現對多個目標的準確成像。
- 時間反演成像 /
- 空頻成像 /
- 空頻分解 /
- 空頻多態響應矩陣
Abstract: Basing on the signal-subspace vectors from the spatial-frequency decomposition, a novel time-reversal imaging algorithm is proposed. Using the backscattered data recorded by the antenna array, a spatial-frequency multistatic matrix is set up. Singular value decomposition is applied to the matrix to obtain the signal-subspace vectors, which are employed to focus the targets imaging selectively. The imaging pseudo-spectrum based on the full backscattered data includes the contributions of multiple sub-vectors and can be viewed as the superposition of multiple images. The algorithm is statistically stable. The random phases, generated by the conventional time-reversal imaging method based on the spatial-spatial decomposition, do not arise in the algorithm. It has excellent capability to resist the noise interference and can accurately focus the multi-targets even when noise with 10 dB SNR is added to the measured data.
- Time-reversal imaging /
- Spatial-frequency imaging /
- Spatial-frequency decomposition /
- Spatial-frequency multistatic matrix

HTML全文

參考文獻(16)

YAVUZ M E and TEIXEIRA F L. A numerical study of time reversed UWB electromagnetic waves in continuous random media[J]. IEEE Antennas and Wireless Propagation Letters, 2005, 4(6): 43-46. doi: 10.1109/LAWP.2005.844117.

DEVANEY A J. Time reversal imaging of obscured targets from multistatic data[J]. IEEE Transactions on Antennas Propagation, 2005, 53(5): 1600-1610. doi: 10.1109/TAP. 2005. 846723.

范晶晶, 趙德雙, 張浩然, 等. 基于時間反演的天線陣列激勵分布確定方法研究[J]. 電子與信息學報, 2014, 36(9): 2238-2243. doi: 10.3724/SP.J.1146.2013.01737.

FAN Jingjing, ZHAO Deshuang, ZHANG Haoran, et al. Array excitation determining method based on time reversal [J]. Journal of Electronics Information Technology, 2014, 36(9): 2238-2243. doi: 10.3724/SP.J.1146.2013.01737.

PRADA C, MANNEVILE S, SPOLIANSKY D, et al. Decomposition of the time reversal operator: Detection and selective focusing on two scatterers[J]. Journal of the Acoustical Society of America, 1996, 99(4): 2067-2076.

YAVUZ M E and TEIXEIRA F L. Full time-domain DORT for ultrawideband fields in dispersive, random inhomogeneous media[J]. IEEE Transactions on Antennas Propagation, 2006, 54(8): 2305-2315. doi: 10.1109/TAP.2006.879196.

KAFAL M, COZZA A, and PICHON L. Locating multiple soft faults in wire networks using an alternative DORT implementation[J]. IEEE Transactions on Instrumentation Measurement, 2016, 65(2): 399-406. doi: 10.1109/TIM.2015. 2498559.

GELAT P, HAAR G T, and SAFFARI N. An assessment of the DORT method on simple scatterers using boundary element modelling[J]. Physics in Medicine and Biology, 2015, 60(9): 3715-3730. doi: 10.1088/0031-9155/60/9/3715.

LEV-ARI H and DEVANEY A J. The time reversal techniques reinterpreted: subspace-based signal processing for multistatic target location[C]. Sensor Array Multichannel Signal Processing Workshop, Cambridge, MA, USA, 2000: 509513. doi: 10.1109/SAM.2000.878061.

YAVUZ M E and TEIXEIRA F L. On the sensitivity of time-reversal imaging techniques to model perturbations[J]. IEEE Transactions on Antennas Propagation, 2008, 56(3): 834-843. doi: 10.1109/TAP.2008.916933.

ISLAM M S and KAABOUCH N. Evaluation of TR-MUSIC algorithm efficiency in detecting breast microcalcifications[C]. IEEE International Conference on Electro/Information Technology, DeKalb, IL, USA, 2015: 617-620. doi: 10.1109/EIT. 2015.7293406.

He J and YUAN F G. Lamb waves based fast subwavelength imaging using a DORT-MUSIC algorithm[C]. American Institute of Physics Conference Series, Minneapolis, MN, USA, 2016,1706(1): 1103-1113.

BORCEA L. Interferometric imaging and time reversal in random media[J]. Inverse Problem, 2003, 18(5): 1247-1279. doi: 10.1007/978-3-540-70529-1_157.

SCHOLZ B. Towards virtual electrical breast biopsy: Space-frequency MUSIC for trans-admittance data[J]. IEEE Transactions on Medical Imaging, 2002, 21(6): 588-595. doi: 10.1109/TMI.2002.800609.

PETROLIS R, RAMONAIT R, JANCIAUSKAS D, et al. Digital imaging of colon tissue: Method for evaluation of inflammation severity by spatial frequency features of the histological images[J]. Diagnostic Pathology, 2015, 10(1): 1-10. doi: 10.1186/s13000-015-0389-7.

CUCCIA D J, BEVILACQUA F, DURKIN A J, et al. Modulated imaging: Quantitative analysis and tomography of turbid media in the spatial-frequency domain[J]. Optics Letters, 2005,30(11): 1354-1356. doi: 10.1364/OL.30.001354.
