二維雙原型完全過采樣DFT調制濾波器組的快速設計方法
doi: 10.11999/JEIT160125
基金項目:
國家自然科學基金(61261032, 61371186)，廣西區自然科學基金 (2013GXNSFBA019264)
Fast Design of 2D and Double-prototype Fully Oversampled DFT Modulated Filter Banks
Funds:
The National Natural Science Foundation of China (61261032, 61371186), The Guangxi Natural Science Foundation (2013GXNSFBA019264)
-
摘要: 傳統的2維大規模濾波器組的設計方法具有復雜度高的缺點。該文提出一種設計2維雙原型濾波器組的快速方法，該方法利用近似完全重構的條件，并采用完全過采樣的離散傅里葉變換(DFT)調制濾波器組來設計。新算法將兩個原型濾波器的設計問題歸結為一個無約束優化問題，其中目標函數為濾波器組的總體失真(傳遞失真和混疊失真)與原型濾波器阻帶能量的加權和，利用目標函數的梯度向量，通過雙迭代機制求解該優化問題。單步迭代中，利用矩陣求逆的等效條件和塊Toeplitz矩陣求逆的快速算法，顯著地降低了計算復雜度。理論分析和數值實驗表明，新算法可以得到整體性能更好的濾波器組，計算復雜度大幅度降低，故可以快速設計大規模的2維濾波器組。
-
關鍵詞:
- 2維離散傅里葉變換 /
- 無約束優化 /
- 完全過采樣 /
- 塊Toeplitz矩陣求逆 /
- 雙迭代算法
Abstract: Traditional design methods of two-dimensional large-scale filter banks suffer from high-complexity. This paper presents an algorithm to design two-dimensional double-prototype fully oversampled Discrete Fourier Transform (DFT) modulated filter bank with Nearly Perfect Reconstruction (NPR). The algorithm is based on bi-iterative scheme, where the design issue is formulated into an unconstrained optimization issue whose objective function is the weighted sum of the transfer distortion and the aliasing distortion of the filter bank, and the stopband energy of the Prototype Filters (PFs). By exploiting the gradient information, the optimization problem can be efficiently solved by utilizing the bi-iterative scheme. The matrix inverse identity and the fast algorithm for Toeplitz-block Toeplitz matrix inversion are employed to dramatically reduce the computational cost of the iterative procedure. The theoretical analysis and numerical experiments are carried out to show that compared with the existing methods, the new algorithm possesses much lower computational cost and can be used to design large-scale two-dimensional filter bank with better overall performance. -
VAIDYANATHAN P P. Multirate Systems and Flter Banks[M]. Englewoo Cliffs: N.J.,Prentice Hall, 1993: 188-272. LIN Y P and VAIDYANATHAN P P. Theory and design of two-dimensional filter bank: A review[J]. Multidimensional System Signal Processing, 1996, 7(3-4): 263-330. doi: 10.1007/BF01826246. GAWANDE J P, RAHULKAR A D, and HOLAMBE R S. Design of new class of regular biorthogonal wavelet filter banks using generalized and hybrid lifting structures[J]. Signal Image and Video Processing, 2015, 9(1): 265-273. doi: 10.1007/s11760-015-0814-0. SHUI Penglang. Image denoising using 2-D separable oversampled DFT modulated filter banks[J]. IET Image Processing, 2009, 3(3): 163-173. doi: 10.1049/iet-ipr.2007.0218. SUZUKI T and KUDO H. Two-dimensional non-separable block-lifting-based M-channel biorthogonal filter banks[C]. European Signal Processing Conference, Lisbon, 2014: 291-295. RAJAPAKAHA N, MADANAYAKE A, and BRUTON LT. 2D space-time wave-digital multi-fan filter banks for signals consisting of multiple plane waves[J]. Multidimensional Systems and Signal Processing, 2014, 25(1): 17-39. doi: 10.1007/s11045-012-0183-6. SUZUKIT and KUDO H. Two-dimensional non-separable block-lifting structure and its application to M-channel perfect reconstruction filter banks for lossy-to-lossless image coding[J]. IEEE Transactions on Image Processing, 2015, 24(12): 4943-4951. doi: 10.1109/TIP.2015.2472294. WILBUR M R, DAVIDSON T N, and REILLY J P. Efficient design of oversampled NPR GDFT filter banks[J]. IEEE Transactions on Signal Processing, 2004, 52(7): 1947-1963. doi: 10.1109/TSP.2004.828936. SHUI Penglang and JIANG Junzheng. Two-dimensional 2 oversampled DFT modulated filter banks and critically sampled modified DFT modulated filter banks[J]. IEEE Transactions on Signal Processing, 2010, 58(11): 5597-5611. doi: 10.1109/TSP.2010.2059016. JIANG Junzheng and ZHOU Fang. Iterative design of two-dimensional critically sampled MDFT modulated filter banks[J]. Signal Processing, 2013, 93(11): 3124-3132. doi: 10.1016/j.sigpro.2013.03.022. JIANG Junzheng, ZHOU Fang, SHUI Penglang, et al. Theory and design of two-dimensional DFT modulated filter bank with arbitrary modulation and decimation matrices[J]. Digital Signal Processing, 2015, 44(1): 123-130. doi: 10.1016/ j.dsp.2015.05.012. JIANG Junzheng and SHUI Penglang. Design of 2D linear phase DFT modulated filter banks using bi-iterative second-order cone program[J]. Signal Processing, 2010, 90(12): 3065-3077. doi: 10.1016/j.sigpro.2010.05.011. JIANG Junzheng and SHUI Penglang. Design of 2D oversampled linear phase DFT modulated filter banks via modified Newtons method[J]. Signal Processing, 2012, 92(6): 1411-1421. doi: 10.1016/j.sigpro.2011.11.029. JIANG Junzheng, ZHOU Fang, and OUYANG Shan. Design of two-dimensional large-scale DFT modulated filter banks[J]. IET Signal Processing, 2013, 7(9): 807-813. doi: 10.1049/ iet-spr.2012.0327. ZHOU Fang, JIANG Junzheng, and SHUI Penglang. Fast design of 2D fully oversampled DFT modulated filter bank using Toeplitz-block Toeplitz matrix inversion[J]. Signal Processing, 2015, 111: 194-198. doi: 10.1016/j.sigpro.2014.12.021. 蔣俊正, 王小龍, 水鵬朗. 一種設計DFT調制濾波器組的新算法[J]. 西安電子科技大學學報, 2010, 37(4): 689-693. doi: 10.3969/j.issn.1001-2400.2010.04.019. JIANG Junzheng, WANG Xiaolong, and SHUI Penglang. Novel method for designing DFT modulated filter banks[J]. Journal of Xidian University, 2010, 37(4): 689-693. doi: 10.3969/j.issn.1001-2400.2010.04.019. WAX M and KAILATH T. Efficient inversion of Toeplitz-block Toeplitz matrix[J]. IEEE Transactions on Acoustics, 1983, 31(5): 1218-1221. doi: 10.1109/TASSP.1983.1164208. -
