矢量傳感器陣列MIMO雷達高精度二維DOA與極化聯合估計

梁浩; 崔琛; 余劍; 郝天鐸

doi:10.11999/JEIT151469

矢量傳感器陣列MIMO雷達高精度二維DOA與極化聯合估計

doi: 10.11999/JEIT151469

基金項目:

國家自然科學基金(60702015)，安徽省科技攻關項目(1310115188)，電子工程學院院控科研基金(KY13A197, KY13A200, KY13A206)

計量
- 文章訪問數: 1264
- HTML全文瀏覽量: 112
- PDF下載量: 419
- 被引次數: 0
出版歷程
- 收稿日期: 2015-12-24
- 修回日期: 2016-07-22
- 刊出日期: 2016-10-19

Joint Estimation of Two Dimensional DOA with High Accuracy and Polarization for MIMO Radar Using Electromagnetic Vector Sensor Arrays

Funds:

The National Natural Science Foundation of China (60702015), Auhui Province Foundation for Science and Technology Research Project (1310115188), Scientific Research Foundation of Electronic Engineering Institute (KY13A197, KY13A200, KY13A206)

摘要

摘要: 該文采用矢量傳感器配置下的十字型陣列MIMO雷達系統，提出一種新的2維高精度DOA與極化參數聯合估計算法。首先根據MIMO雷達虛擬陣列導向矢量的特點，通過降維矩陣的設計及回波數據的降維變換，將高維回波數據轉換至低維信號空間；然后基于傳播算子獲得對應信號子空間的估計，利用收、發陣列陣元間長基線對應的旋轉不變性和極化矢量中電場矢量和磁場矢量的叉積進行2維高精度DOA估計和解模糊處理，同時利用與陣列結構無關的極化域旋轉不變性進行極化輔角和極化相位差的聯合估計。該矢量傳感器MIMO雷達陣列可同時獲取MIMO雷達的波形分集和矢量傳感器的極化分集，無需額外增加陣元和硬件開銷，能夠有效擴展陣列孔徑，提高參數估計性能；同時通過降維變換及傳播算子，在獲取信噪比增益的同時，能夠實現2維高精度DOA和2維極化矢量的聯合估計及參數的自動配對，有效降低數據處理維數和參數估計的運算復雜度；最后，仿真結果驗證了理論分析的正確性和算法的有效性。
- MIMO雷達 /
- 矢量傳感器陣列 /
- 高精度DOA估計 /
- 極化參量
Abstract: In this paper, monostatic MIMO radar with cross array using electromagnetic vector antennas is utilized and a novel algorithm for fast Two Dimensional (2D) Direction Of Arrival (DOA) with high accuracy and polarization estimation is proposed. First, given the virtual steering vector of monostatic MIMO radar, a reduced-dimensional matrix is employed and the high dimensional received data is transformed into a lower dimensional signal space via the reduced-dimensional transformation. Then the Propagator Method (PM) is utilized to estimate the corresponding signal subspace by linear operation. Second, rotational invariance relationships with long baseline in the proposed scheme and polarization vector cross product between the normalized electric vector and the normalized magnetic vector can be used to obtain the 2D DOA estimation with high accuracy and non-ambiguity. The polarization rotational invariance relationship, which is irrespective of array geometry, is utilized to estimate the auxiliary polarization angle and polarization phase difference. The proposed system, extending array aperture without increasing sensors and hardware costs, can obtain the waveform diversity offered by MIMO radar and the polarization diversity offered by vector sensor together and achieve better estimation performance. Meanwhile, through the reduced-dimensional and linear operation, the proposed algorithm, obtaining signal to ratio gain and joint estimation for 2D DOA with high accuracy and 2D polarization parameters with automatic pairing, can reduce the dimension of received data and the computational complexity of parameters estimation effectively. Lastly, simulation results verify the correctness of theoretical analysis and the effectiveness of proposed algorithm.
- MIMO radar /
- Vector sensor array /
- High accurate DOA estimation /
- Polarization parameters

HTML全文

參考文獻(31)

HULEIHEL W, TABRIKIAN J, and SHAVIT R. Optimal adaptive waveform design for cognitive MIMO radar[J]. IEEE Transactions on Signal Processing, 2013, 61(20): 5075-5089. doi: 10.1109/TSP.2013.2269045.

WANG P, LI H B, and HIMED B. A parametric moving target detector for distributed MIMO radar in non- homogeneous environment[J]. IEEE Transactions on Signal Processing, 2013, 61(9): 2282-2294. doi: 10.1109/TSP.2013. 2245323.

ZHANG X, HUANG Y, CHEN C, et al. Reduced-complexity Capon for direction of arrival estimation in a monostatic multiple -input multiple-output radar[J]. IET Radar, Sonar and Navigation, 2012, 6(8): 796-801. doi: 10.1049/iet-rsn. 2011.0343.

ZHANG X and XU D. Low-complexity ESPRIT-based DOA estimation for colocated MIMO radar using reduced- dimension transformation[J]. Electronics Letters, 2011, 17(47): 283-284. doi: 10.1049/el.2010.3279.

文才, 王彤. 單基地MIMO雷達降維酉ESPRIT算法[J].系統工程與電子技術, 2014, 36(6): 1062-1067. doi: 10.3969/j.issn. 1001- 506X.2014.06.08.

WEN C and WANG T. Reduced-dimensional unitary ESPRIT algorithm for monostatic MIMO radar[J]. Systems Engineering and Electronics, 2014, 36(6): 1062-1067. doi: 10.3969/j.issn.1001-506X.2014.06.08.

WANG W, WANG X, SONG H, et al. Conjugate ESPRIT for DOA estimation in monostatic MIMO radar[J]. Signal Processing, 2013, 93(7): 2070-2075. doi: 10.1016/j.sigpro. 2013.01.007.

LI J F, ZHANG X F, CHEN W Y, et al. Reduced- dimensional ESPRIT for direction finding in monostatic MIMO radar with double parallel uniform linear arrays[J]. Wireless Personal Communications, 2014, 77(1): 1-19. doi: 10.1007/s11277-013-1491-3.

王偉, 王曉萌, 李欣, 等. 基于MUSIC算法的L型陣列MIMO雷達降維DOA估計[J]. 電子與信息學報, 2014, 36(8): 1954-1959. doi: 10.3724/SP.J.1146.2013.01281.

WANG W, WANG X M, LI X, et al. Reduced-dimensional DOA estimation based on MUSIC algorithm in MIMO radar with L-shaped array[J]. Journal of Electronics Information Technology, 2014, 36(8): 1954-1959. doi: 10.3724/ SP.J.1146. 2013.01281.

梁浩, 崔琛, 代林, 等. 基于ESPRIT算法的L型陣列MIMO雷達降維DOA估計[J]. 電子與信息學報, 2015, 37(8): 1928-1935. doi: 10.11999/JEIT141295.

LIANG H, CUI C, DAI L, et al. Reduced-dimensional DOA estimation based on ESPRIT algorithm in MIMO radar with L- shaped array[J]. Journal of Electronics Information Technology, 2015, 37(8): 1928-1935. doi: 10.11999/JEIT141295.

LI J F and ZHANG X F. Unitary reduced-dimensional estimation of signal parameters via rotational invariance techniques for angle estimation in monostatic multiple-input-multiple-output radar with rectangular arrays [J]. IET Radar, Sonar and Navigation, 2014, 8(6): 575-584. doi: 10.1049/iet-rsn.2013.0269.

ZHENG G M and CHEN B X. Unitary dual-resolution ESPRIT for joint DOD and DOA estimation in bistatic MIMO radar[J]. Multidimensional Systems and Signal Processing, 2015, 26(1): 159-178. doi: 10.1007/s11045-013-0244-5.

ZHENG G M, CHEN B X, and YANG M L. Unitary ESPRIT algorithm for bistatic MIMO radar[J]. Electronics Letters, 2012, 48(3): 179-181. doi: 10.1049/el.2011.3657.

JIANG H, WANG D F, and LIU C. Joint estimation of DOD/DOA/polarization parameters of bistatic MIMO radar[J]. The Journal of China Universities of Posts and Telecommunications, 2010, 17(5): 32-37. doi: 10.1016/S1005- 8885(09)60504-5.

ZHOU M and ZHANG X F. Joint estimation of angle and polarization for bistatic MIMO radar with polarization sensitive array using dimension reduction MUSIC[J]. Wireless Personal Communications, 2015, 81(3): 1333-1345. doi: 10.1007/s11277-014- 2187-z.

王克讓, 朱曉華, 何勁. 基于矢量傳感器MIMO雷達的DOD/DOA和極化聯合估計算法[J]. 電子與信息學報, 2012, 34(1): 160-165. doi: 10.3724/SP.J.1146.2011.00576.

WANG K R, ZHU X H, and HE J. Joint DOD DOA and polarization estimation for MIMO radar with electromagnetic vector sensors[J]. Journal of Electronics Information Technology, 2012, 34(1): 160-165. doi: 10.3724/ SP.J.1146.2011.00576.

王克讓, 何勁, 賀亞鵬, 等. 基于矢量傳感器的擴展孔徑雙基地MIMO 雷達多目標定位算法[J]. 電子與信息學報, 2012, 34 (4): 582-586. doi: 10.3724/SP.J.1146.2011.00801.

WANG K R, HE J, HE Y P, et al. Extended-aperture mulit-target location algorithm for MIMO radars with vector sensors[J]. Journal of Electronics Information Technology, 2012, 34(4): 582-586. doi: 10.3724/SP.J.1146.2011.00801.

鄭桂妹, 楊明磊, 陳伯孝, 等. 干涉式矢量傳感器MIMO雷達的DOD/DOA和極化聯合估計[J]. 電子與信息學報, 2012, 34(11): 2635-2641. doi: 10.3724/SP.J.1146.2012.00407.

ZHENG G M, YANG M L, CHEN B X, et al. Joint DOD/DOA and polarization estimation for interferometric MIMO radar with electromagnetic vector sensors[J]. Journal of Electronics Information Technology, 2012, 34(11): 2635-2641. doi: 10.3724/SP.J.1 146.2012.00407.

GU C, HE J, Li H, et al. Target localization using MIMO electromagnetic vector array systems[J]. Signal Processing, 2013, 93(7): 2103-2107. doi: 10.1016/j.sigpro.2013.02.005.

鄭桂妹, 陳伯孝, 楊明磊. 基于矢量傳感器MIMO雷達的發射極化優化DOA估計算法[J]. 電子與信息學報, 2014, 36(3): 565-570. doi: 10.3724/SP.J.1146.2013.00648.

ZHENG G M, CHEN B X, and YANG M L. Transmitted polarization optimization for DOA estimation based on vector sensor MIMO radar[J]. Journal of Electronics Information Technology, 2014, 36(3): 565-570. doi: 10.3724/ SP.J.1146.2013.00648.

梁浩, 崔琛, 余劍. 基于ESPRIT算法的十字型陣列MIMO雷達降維DOA估計[J]. 電子與信息學報, 2016, 38(1): 80-89. doi: 10.11999/JEIT150402.

LIANG H, CUI C, and YU J. Reduced-dimensional DOA stimation based on ESPRIT algorithm in monostatic MIMO radar with cross array [J]. Journal of Electronics Information Technology, 2016, 38(1): 80-89. doi: 10.11999 /JEIT150402.

CHEN D F, CHEN B X, and GUO D Q. Angle estimation using ESPRIT in MIMO radar[J]. Electronics Letters, 2008, 44(12): 770-771. doi: 10.1049/el:20080276.

CHEN J L, GU H, and SU W M. Angle estimation using ESPRIT without pairing in MIMO radar[J]. Electronics Letters, 2008, 44(24): 1422-1423. doi: 10.1049/el:20089089.

LEMMA A N, VEEN A J, and DEPRETTERE E F. Multiresolution ESPRIT algorithm[J]. IEEE Transactions on Signal Processing, 1999, 47(6): 1722-1726. doi: S 1053-587X (99)03682-X.
