基于改進GA-FFT綜合含互耦效應的不等間隔陣列賦形方向圖

游鵬飛; 劉顏回; 黃鑫; 朱春輝; 柳清伙

doi:10.11999/JEIT151189

基于改進GA-FFT綜合含互耦效應的不等間隔陣列賦形方向圖

doi: 10.11999/JEIT151189

1.
(廈門大學電子科學系廈門 361005) ②(杜克大學電氣與計算機工程系達勒姆 27708)

基金項目:

國家自然科學基金(61301009)，中央高校基本科研業務費(20720160081)

計量
- 文章訪問數: 1694
- HTML全文瀏覽量: 217
- PDF下載量: 424
- 被引次數: 0
出版歷程
- 收稿日期: 2015-10-29
- 修回日期: 2016-04-08
- 刊出日期: 2016-08-19

Modified GA-FFT for Synthesizing Shaped Pattern of Unequally Spaced Array in Presence of Mutual Coupling

1.
(Department of Electronic Science, Xiamen University, Xiamen 361005, China)
2.
(Department of Electrical and Computer Engineering, Duke University, Durham 27708, USA)

Funds:

The National Natural Science Foundation of China (61301009), The Fundamental Research Funds for the Central Universities (20720160081)

摘要

摘要: 該文提出了一種虛擬的最小均方有源單元方向圖展開方法，將不等間隔陣列的有源方向圖展開為一個虛擬的均勻間隔陣列的若干單元輻射的疊加。通過該方法，對包含陣元耦合效應的不等間隔陣列方向圖，可以使用快速傅里葉變換進行加速計算。并且，該文將這個方法與遺傳算法(GA)相結合，得到一種改進的GA-FFT方法，可以應用于解決含陣元互耦的不均勻間隔陣列的賦形波束綜合問題。最后，分別對不等間隔的偶極子陣列平頂方向圖及微帶陣列的余割平方方向圖進行了綜合，結果表明所提方法的有效性和優勢。
- 不等間隔陣列 /
- 陣元互耦 /
- FFT /
- 波束賦形
Abstract: A new Virtual Least-Square Active Element Pattern Expansion (VLS-AEPE) method is presented in this paper, which considers each active element pattern of an unequally spaced array as the one radiated by some of equally spaced elements of a virtual array. Using the help of this method, the pattern of an unequally spaced array including mutual coupling can be efficiently calculated by FFT. In addition, this method is combined with the Genetic Algorithm (GA) to deal with the shaped pattern synthesis problem for unequally spaced linear arrays. Two synthesis experiments including the synthesis of flat-top pattern for an unequally spaced dipole array and the synthesis of cosec-squared pattern for an unequally spaced microstrip array are conducted to verify the effectiveness and advantages of the proposed algorithm.
- Unequally spaced linear array /
- Element mutual coupling /
- FFT /
- Shaped pattern synthesis

HTML全文

參考文獻(18)

WANG X, ABOUTANIOS E, and AMIN M G. Thinned array beampattern synthesis by iterative soft-thresholding- based optimization algorithms[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(12): 6102-6113. doi: 10. 1002/MOP.10823.

趙宜楠, 張濤, 李風從, 等. 基于交替投影的MIMO雷達最優波形設計[J]. 電子與信息學報, 2014, 36(6): 1368-1373. doi: 10.3724/SP.J.1146.2013.01198.

ZHAO Y N, ZHANG T, LI F C, et al. Optimal waveform design for MIMO radar via alternating projection[J]. Journal of Electronics Information Technology, 2014, 36(6): 1368-1373. doi: 10.3724/SP.J.1146.2013.01198.

于波, 陳客松, 朱盼, 等. 稀布圓陣的降維優化方法[J]. 電子與信息學報, 2014, 36(2): 476-481. doi: 10.3724/SP.J.1146. 2013.00526.

YU B, CHEN K S, ZHU P, et al. An optimum method of sparse concentric rings array based on dimensionality reduction[J]. Journal of Electronics Information Technology, 2014, 36(2): 476-481. doi: 10.3724/SP.J.1146. 2013.00526.

WANG L L, FANG D G, and SHENG W X. Combination of Genetic Algorithm(GA) and Fast Fourier Transform(FFT) for synthesis of arrays[J]. Microwave and Optical Technology Letters, 2003, 37(1): 56-79. doi: 10.1002/MOP.10823.

LIU Q H and NGUYEN N. An accurate algorithm for NonUniform Fast Fourier Transforms (NUFFT,s)[J]. IEEE Microwave and Guided Wave Letters, 1998, 8(1): 18-20. doi: 10.1109/75.650975.

YANG K, ZHAO Z Q, and LIU Q H. Fast pencil beam pattern synthesis of large unequally spaced antenna arrays[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(2): 627-634. doi: 10.1109/TAP.2012.2220319.

LIU J Z, ZHAO Z Q, YANG K, et al. A hybrid optimization for pattern synthesis of large antenna arrays[J]. Progress In Electromagnetics Research, 2014, 145: 81-91. doi: 10.2528/ PIER13121606.

JIANG M L, CHEN R S, ZHOU L, et al. Synthesis of arrays with Genetic Algorithm(GA) and Nonuniform Fast Fourier Transform (NFFT)[C]. Asia-Pacific Microwave Conference Proceedings(APMC), Suzhou, China, 2005, 4: 2. doi: 10. 1109/APMC.2005.1606885.

POZAR D M. The active element pattern[J]. IEEE Transactions on Antennas Propagation, 1994, 42(8): 1176-1178. doi: 10.1109/8.310010.

POZAR D M. A relation between the active input impedance and the active element pattern of a phased array[J]. IEEE Transactions on Antennas and Propagation, 2003, 51(9): 2486-2489. doi: 10.1109/TAP.2003.816302.

KELLY D F and STUTZMAN W L. Array antenna pattern modeling methods that include mutual coupling effects[J]. IEEE Transactions on Antennas and Propagation, 1993, 41(12): 1625-1632. doi: 10.1109/8.273305.

STEYSKAL H and HERD J S. Mutual coupling compensation in small array antennas[J]. IEEE Transactions on Antennas and Propagation, 1990, 38(12): 1971-1975. doi: 10.1109/8.60990.

YOU P F, LIU Y H, HUANG X, et al. Efficient phase-only linear array synthesis including coupling effect by GA-FFT based on least-square active element pattern expansion method[J]. Electronics Letters, 2015, 51(10): 791-792. doi: 10.1049/EL.2015.0431.

LIU Y H, NIE Z P, and LIU Q H. A new method for the synthesis of non-uniform linear arrays with shaped power patterns[J]. Progress In Electromagnetics Research, 2010, 107: 349-363. doi: 10.2528/PIER10060912.

WANG F, BALAKRISHNAN V, ZHOU P Y, et al. Optimal array pattern synthesis using semidefinite programming[J]. IEEE Transactions on Signal Processing, 2003, 51(5): 1172-1183. doi: 10.1109/TSP.2003.810308.

FUCHS B. Synthesis of sparse arrays with focused or shaped beampattern via sequential convex optimizations[J]. IEEE Transactions on Antennas and Propagation, 2012, 60(7): 3499-3503. doi: 10.1109/TAP.2012.2196951.
