一種基于MEMS芯片的新型地面大氣電場傳感器
doi: 10.11999/JEIT150994
-
1.
(北京大學微米/納米加工技術國家重點實驗室 北京 100871) ②(中國科學院電子學研究所傳感器技術國家重點實驗室 北京 100190) ③(清華大學微電子學研究所 北京 100084)
基金項目:
國家自然科學基金項目(61327810, 61201078)，國家自然科學基金重大儀器專項(61302032)
A Novel MEMS Chip-based Ground Atmospheric Electric Field Sensor
-
1.
(National Key Laboratory of Micro/Nano Fabrication Technology, Peking University, Beijing 100871, China)
-
2.
(State Key Laboratory of Transducer Technology, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
Funds:
The National Natural Science Foundation of China (61327810, 61201078), The National Major Scientific Research Equipment Development of National Natural Science Foundation of China (61302032)
-
摘要: 該文基于MEMS電場敏感芯片，研制出了一種新型的地面大氣電場傳感器，解決了現有場磨式電場儀易磨損、功耗大、故障率高等問題。敏感芯片采用SOIMUMPS加工工藝制備，其芯片面積僅為5.5 mm5.5 mm。該文提出了傳感器敏感芯片的弱信號檢測方法，設計出了滿足環境適應性的傳感器整體結構方案，并建立了傳感器的靈敏度分析模型。對電場傳感器進行測試，測量范圍為-50 kV/m~50 kV/m，總不確定度為0.67%，分辨力達到10 V/m，功耗僅為0.62 W。外場試驗結果表明，MEMS地面大氣電場傳感器在晴天和雷暴天的電場探測結果，與Campbell公司場磨式電場儀探測結果都有較好的一致性，說明該傳感器能滿足預測雷暴要求，實現雷電監測和預警功能。
-
關鍵詞:
- 微機電系統 /
- 電場傳感器 /
- MEMS地面大氣電場傳感器
Abstract: In this paper, a novel ground atmospheric electric field sensor based on MEMS electric field sensing chip is presented, which resolves the problems of motor wear, high power consumption and failure rate of the conventional electric field mill. The chip is fabricated in a commercial SOIMUMPS process, and the area of this chip is only 5.5 mm5.5 mm. A weak signal detection method for the chip is proposed. The sensor overall structure scheme is designed, and the sensitivity model is established. The minimum detectable electric field of the sensor is 10 V/m with an uncertainty of 0.67% in the range of -50 kV/m～50 kV/m, and its power consumption is only 0.62 W. The outdoor test shows that the plotted data of the sensor agrees well with those of USA Campbell field mill on both sunny days and thunderstorm days, which indicates that the developed sensor can meet the requirement of lighting monitoring and early warning. -
謝云云, 薛禹勝, 王昊昊, 等. 電網雷擊故障概率的時空在線預警[J]. 電力系統自動化, 2013, 37(17): 44-51. XIE Yunyun, XUE Yusheng, WANG Haohao, et al. Space-time early-warning of power grid fault probability by lightning[J]. Automation of Electric Power Systems, 2013, 37(17): 44-51. MONTANYA J, BERGAS J, and HERMOSO B. Electric field measurements at ground level as a basis for lightning hazard warning[J]. Journal of Electrostatics, 2004, 60: 241-246. KAPLAN Benzion. Duality of the electric covering field mill and the fluxgate magnetometer[J]. IEEE Transactions on Magnetics, 1998, 34(4): 2306-2315. RIEHL P S, SCOTT K L, MULLER R S, et al. Electrostatic charge and field sensors based on micromechanical resonators[J]. Journal of Microelectromechanical Systems, 2003, 12(5): 577-589. BAHREYNI B, WIJEWEERA G, SHAFAI C, et al. Analysis and design of a micromachined electric-field sensor[J]. Journal of Microelectromechanical Systems, 2008, 17(1): 31-36. KONBAYASHI Takeshi, OYAMA Syoji, TAKAHASHI Masaharu, et al. Microelectromichanical systems-based electrostatic field sensor using Pb (Zr, Ti)O3 thin films[J]. Japanese Journal of Applied Physics, 2008, 47(9): 7533-7536. PENG Chunrong, CHEN Xianxiang, BAI Qiang, et al. A novel high performance micromechanical resonant electrostatic field sensor used in atmospheric electric field detection[C]. Proc. 19th IEEE MEMS, Istanbul, Turkey, 2006: 698-701. PENG Chunrong, YANG Pengfei, WEN Xiaolong, et al. Design of a novel micromachined non-contact resonant voltage sensor for power distribution systems[C]. IEEE Sensors, Valencia, Spain, 2014: 978-981. 聞小龍, 彭春榮, 方東明, 等. 基于共面去耦結構的空間三維電場測量方法[J] .電子與信息學報, 2014, 36(10): 2504-2508. doi: 10.3724/SP.J.1146.2013.01921. WEN Xiaolong, PENG Chunrong, FANG Dongming, et al. Measuring method of three dimensional atmospheric electric field based on coplanar decoupling structrure[J]. Journal of Electronics Information Technology, 2014, 36(10): 2504-2508. doi: 10.3724/SP.J.1146.2013.01921. WEN Xiaolong, FANG Dongming, PENG Chunrong, et al. Three dimensional electric field measurement method based on coplanar decoupling structure[C]. IEEE Sensors, Valencia, Spain, 2014: 582-585. WEN Xiaolong, PENG Chunrong, FANG Dongming, et al. High performance electric field micro sensor with combined differential structure[J]. Journal of Electronics (China), 2014, 31(2): 143-150. WANG Yu, FANG Dongming, FENG Ke, et al. A novel 2-dimensional electric field sensor based on in-plane micro rotary actuator[C]. IEEE Sensors, Valencia, Spain, 2014: 1924-1927. 楊鵬飛, 彭春榮, 張海巖, 等. SOI微型電場傳感器的設計與測試[J].電子與信息學報, 2011, 33(11): 2771-2774. doi: 10.3724/SP.J.1146.2010.01285. YANG Pengfei, PENG Chunrong, ZHANG Haiyan, et al. Design and testing of a SOI electric-field microsensor[J]. Journal of Electronics Information Technology, 2011, 33(11): 2771-2774. doi: 10.3724/SP.J.1146.2010.01285. YANG Pengfei, PENG Chunrong, ZHANG Haiyan, et al.. A high sensitivity SOI electric-field sensor with novel comb-shaped microelectrodes[C]. 16th International Conference on Solid-State Sensors, Actuators Microsystems (Tranducers11), Beijing, China, 2011: 1034-1037. YANG Pengfei, PENG Chunrong, FANG Dongming, et al. Design, fabrication and application of an SOI-based resonant electric field microsensor with coplanar comb-shaped electrodes[J]. Journal of Micromechanics and Microengineering, 2013, 23, 055002: 8pp. -
