基于時分MIMO的地基雷達高分辨率成像研究

蔣留兵,  楊濤,  車?yán)?/a>

蔣留兵, 楊濤, 車?yán)? 基于時分MIMO的地基雷達高分辨率成像研究[J]. 電子與信息學報, 2016, 38(5): 1055-1063. doi: 10.11999/JEIT150905
引用本文: 蔣留兵, 楊濤, 車?yán)? 基于時分MIMO的地基雷達高分辨率成像研究[J]. 電子與信息學報, 2016, 38(5): 1055-1063. doi: 10.11999/JEIT150905
JIANG Liubing, YANG Tao, CHE Li. Study on High-resolution Imaging of Ground-based MIMO Radar Based on Time-division Multiplexing[J]. Journal of Electronics & Information Technology, 2016, 38(5): 1055-1063. doi: 10.11999/JEIT150905
Citation: JIANG Liubing, YANG Tao, CHE Li. Study on High-resolution Imaging of Ground-based MIMO Radar Based on Time-division Multiplexing[J]. Journal of Electronics & Information Technology, 2016, 38(5): 1055-1063. doi: 10.11999/JEIT150905

Study on High-resolution Imaging of Ground-based MIMO Radar Based on Time-division Multiplexing
Funds:

The National Natural Science Foundation of China (61561010), Guangxi Natural Science Foundation (2013- GXNSFAA019323), Guangxi Scientific Research and Technological Development Project (guikegong 14122006-6), Guangxi Department of Education Research Project (KY2015LX096), Project of Guangxi Key Laboratory of Wireless Broadband Communications and Signal Processing Director Foundation (GXKL061506)

  • 摘要: 基于時分多輸入多輸出(MIMO)的地基雷達成像有許多很好的應用價值，比如替代合成孔徑雷達成像在山體滑坡監測方面的應用。針對基于時分MIMO的地基雷達高效高分辨率成像，該文提出一種基于逆傅里葉變換脈沖壓縮和波束形成的成像算法。雷達通過步進頻連續波技術獲得高距離向分辨率，利用MIMO技術獲得高方位向分辨率。通過逆傅里葉變換法實現雷達數據距離向壓縮，采用波束形成算法實現雷達數據方位向壓縮。同時該算法還針對MIMO天線陣列所引起的回波信號相位不連續問題進行了適當?shù)男Ｕ诒３炙惴ǜ咝缘耐瑫r(shí)提高了成像質量。根據真實的山體滑坡監測成像場景參數，通過數值仿真驗證了該成像算法的可行性，應用在山體滑坡監測上理論效果良好。
    Abstract: Ground-based radar imaging based on time-division multiplexing MIMO can be used in many important applications, such as application to landslide monitoring in place of synthetic aperture radar imaging. For efficient high-resolution imaging of the ground-based radar based on time-division multiplexing MIMO, an imaging algorithm based on Inverse Fast Fourier Transform (IFFT) pulse compression and beamforming is proposed. High range resolution is obtained by stepped frequency continuous wave technology and high azimuth resolution is obtained by MIMO technology. The range compression of radar data is realized by IFFT and the cross-range compression of radar data is realized by beamforming algorithm. Furthermore, phase discontinuity problem of received signal caused by MIMO antenna arrays is appropriately corrected in the algorithm, both efficiency of this algorithm and imaging quality are also improved. A numerical simulation proves feasibility of this imaging algorithm according to the practical parameters in monitoring and imaging scenario of landslide, and the proposed imaging algorithm has good theoretical performance when it is applied to landslide monitoring.
