基于簡縮極化干涉SAR數據的森林垂直參數反演

郭勝龍; 李洋; 尹嬙; 王建峰; 洪文

doi:10.11999/JEIT150394

基于簡縮極化干涉SAR數據的森林垂直參數反演

doi: 10.11999/JEIT150394

計量
- 文章訪問數: 1428
- HTML全文瀏覽量: 170
- PDF下載量: 522
- 被引次數: 0
出版歷程
- 收稿日期: 2015-04-08
- 修回日期: 2015-09-24
- 刊出日期: 2016-01-19

Vertical Parameters Estimation of Forest with Compact Polarimetric SAR Interferometry Data

摘要

摘要: 森林區域豎直結構參數的反演是極化干涉雷達的一個重要應用，基于RVoG模型，運用全極化干涉數據可成功獲得森林區域的地形估計及樹高反演。該文將基于單基線簡縮極化干涉SAR(C-PolInSAR)數據對森林區域進行林下地形估計及樹高反演。推導單基線簡縮極化干涉相干系數及相干區域，根據相干區域進行直線擬合，提出簡縮極化干涉數據下的地形相位判別準則及體散射去相干估計方法，然后完成樹高反演。通過L, P波段仿真數據以及實測機載數據對上述方法進行驗證，獲得正確地形及樹高。簡縮極化發射波極化狀態不唯一，因此該文詳細分析不同參數的橢圓極化對地形及樹高等參數估計的影響，研究表明地形樹高受橢圓極化波影響較小，也驗證了估計方法的穩定性。
- 合成孔徑雷達 /
- 簡縮極化干涉SAR /
- 地形估計 /
- 樹高反演
Abstract: Vertical parameters estimation of forest is one of the most important applications in the Polarimetric Interferometric SAR (PolInSAR). On the basis of the Radom Volume over Ground (RVoG) model, the topographical phase and the tree height in forest area can be successfully estimated with the PolInSAR data. In this paper, the topographical phase and forest heights are obtained with single-baseline Compact Polarimetric Interferometric SAR (C-PolInSAR) data. This paper introduces the complex coherence coefficients and the coherence region of the single-baseline C-PolInSAR. Firstly, line-fitting technique is performed on the basis of the coherence region, then the criterion for estimating the topography, and the only volume de-correlation are proposed with the compact polarimetric SAR interferometry datasets. Finally, the topography and the forest heights are proposed. The simulated L, and P band data is used to validate the proposed method, and the topography and tree heights are obtained successfully. Since the transmit wave polarization state of the compact polarimetric system is not unique, this paper analyzes the influence of the elliptic-polarization with different elliptical parameters on the topographical phase and the forest heights. Results show that elliptic-polarization has a little impact on vertical parameters, which also validates the stability of the estimation method.
- SAR /
- Compact Polarimetric Interferometric SAR (C-PolInSAR) /
- Topography estimation /
- Forest heights estimation

HTML全文

參考文獻(17)

CTLROUDE S R and PAPATHANASSIOU K P. Three-stage inversionprocess for polarimetric SAR interferometry[J]. IEE Proceedings-Radar, Sonar and Navigation, 2003, 150(3): 125-134.

TREUHAFTR N and SIQUEIRA P R. The vertical structure of vegetated land surfaces from interferometric and polarimetric radar[J]. Radio Science, 2000, 35(1): 141-177.

CHEN H, CTLROUDE S R, and GOODENOUGH D G. Compact radar polarimetry forfirescar mapping andland cover CTLRassification[C]. Proceedings of the IET International Radar Conference, Xian, China, 2013: 1-4.

陳琳. 簡縮極化SAR信息處理模型與方法研究[D]. [博士論文], 中國科學院電子學研究所, 2013.

CHEN Lin. Investigation on models and methods of compact polarimetric SAR information processing[D]. [Ph.D. dissertation], Institute of Electronics, Chinese Academy of Sciences, 2013.

SOUYRIS J C, IMBO P, FJORTOFT R, et al. Compact polarimetry based on symmetry properties of geophysical media: the pi/4 mode[J]. IEEE Transactions on Geoscience and Remote Sensing, 2005, 43(3): 634-646.

RANEY R K. Hybrid-polarity SAR architecture[J]. IEEE Transactions on Geoscience and Remote Sensing, 2007, 45(11): 3397-3404.

COLLINS M J, DENBINA M, and ATTEIA G. On the reconstruction of quad-Pol SAR data fromcompact polarimetry data for ocean target detection[J]. IEEE Transactions on Geoscience and Remote Sensing, 2013, 51(1): 591-600.

NORD M E, AINSWORTH T L, LEE J S, et al. Comparison of compact polarimetric synthetic aperture radar modes[J]. IEEE Transactions on Geoscience and Remote Sensing, 2009, 47(1): 174-188.

SALBERG A B, RUDJORD ?, and SOLBERG A H S. Oil spill detection in hybrid-polarimetricSARimage[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(10): 6521-6533.

郭勝龍, 李洋, 洪文, 等. 基于模型的模式簡縮極化干涉數據目標分解[J]. 電子與信息學報, 2015, 37(1): 22-28. doi: 10.11999/ JEIT140550.

GUO Shenglong, LI Yang, HONG Wen, et al. Model-based target decomposition with mode compact polarimetric SAR interferometry data[J]. Journal of Electronics Information Technology, 2015, 37(1): 22-28. doi: 10.11999/ JEIT140550.

SABRY RAND VACHON P W. A unified framework for general compact andquad polarimetric SAR data and imagery analysis[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(1): 582-602.

ARNAUBEC A, ROUEFF A, REFREGIER P, et al. Vegetation height estimation precision with compact PolInSAR and homogeneous Random Volume over Ground model[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(3): 1879-1891.

POTTIER E. ProSARPro_v4.2.0[OL]. https://earth.esa.- int/ web/polsarpro, 2012.

許麗穎, 李世強, 鄧云凱, 等. 基于極化干涉SAR 反演植被高度的改進三階段算法[J]. 雷達學報. 2014, 3(1): 28-34.

XU Liying, LI Shiqiang, DENG Yunkai, et al. Improved three-stage algorithm of forest height retrieval with PolInSAR[J]. Journal of Radars, 2014, 3(1): 28-34.
