基于迭代散射算法的柱體陣列散射場分析

劉起坤; 周東方; 邢鋒; 雷雪; 余道杰

doi:10.11999/JEIT150167

基于迭代散射算法的柱體陣列散射場分析

doi: 10.11999/JEIT150167

基金項目:

國家自然科學基金(62101056)和國家863計劃項目(2014AA01A707)

計量
- 文章訪問數: 1178
- HTML全文瀏覽量: 115
- PDF下載量: 433
- 被引次數: 0
出版歷程
- 收稿日期: 2015-01-29
- 修回日期: 2015-05-06
- 刊出日期: 2015-09-19

Analysis on Scattering Characteristics of Cylinder Array Based on Iterative Scattering Algorithm

摘要

摘要: 該文基于迭代散射算法(ISP)對柱體陣列的散射場進行分析。通過矢量柱面波函數展開，根據理想導體表面邊界條件，建立柱體表面入射場與散射場的關系式。將前一次迭代時柱體陣列的近區散射場作為下一次迭代的入射場，推導出柱體陣列散射場系數間的迭代關系。通過分析不同迭代次數下2~4個柱體的散射場，確定3次迭代即可保證算法的準確度。對比數值結果表明，迭代散射算法具有與矩量法(MoM)結果同等的準確度，并具有明顯優于矩量法的計算速度。
- 電磁散射 /
- 迭代散射算法 /
- 多次散射 /
- 柱體陣列 /
- 矩量法
Abstract: Based on Iterative Scattering Process (ISP) algorithm, the scattering characteristics of cylinder array are analyzed. The relationship between incident field and scattering filed can be evolved from the cylindrical harmonic functions under surface boundary condition of perfect conductor. With the previous iterative scattering fields among cylinders being the incident field next iteration, the coefficient relationship of scattering fields among cylinder array is derived. After analyzing the scattering fields of two or four cylinders within different iterations, it can be obtained that the calculated result of ISP algorithm keeps high accuracy with only three iterations. The results compared with numerical methods show that ISP algorithm and Method of Moments (MoM) agree well, whereas ISP algorithm has an observably faster calculated pace.
- Electromagnetic scattering /
- Iterative Scattering Process (ISP) algorithm /
- Multiple scattering /
- Cylinder array /
- Method of Moments (MoM)

HTML全文

參考文獻(19)

程志華, 謝擁軍, 樊君. 復雜目標的太赫茲波近場RCS快速計算[J]. 電子與信息學報, 2014, 36(8): 1999-2004.

Cheng Zhi-hua, Xie Yong-jun, and Fan Jun. Fast computation of near field RCS of complex objects in terahertz band[J]. Journal of Electronics Information Technology, 2014, 36(8): 1999-2004.

李曉峰, 謝擁軍, 楊銳. 半空間電大導體目標散射的高頻分析方法[J]. 電子與信息學報, 2009, 31(5): 1268-1270.

Li Xiao-feng, Xie Yong-jun, and Yang Rui. High-frequency analysis on scattering from conductive targets with electrically large size in half space[J]. Journal of Electronics Information Technology, 2009, 31(5): 1268-1270.

Nasr M A, Eshrah I A, and Hashish E A. Electromagnetic scattering from a buried cylinder using a multiple reflection approach: TM case[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(5): 2702-2707.

Wu Xiao-po, Shi Jia-ming, and Wang Jia-chun. Multiple scattering by parallel plasma cylinders[J]. IEEE Transactions on Plasma Science, 2014, 42(1): 13-19.

張會云, 劉蒙, 尹貽恒, 等. 基于格林函數法研究金屬線柵在太赫茲波段的散射特性[J]. 物理學報, 2013, 62(19): 240-245.

Zhang Hui-yun, Liu Meng, Yin Yi-heng, et al.. Study on scattering properties of the metal wire gating in a THz band based on Green function method[J]. Acta Phasica Sinica, 2013, 62(19): 240-245.

Kim K T and Kramer B A. Direct determination of the T-matrix from a mom impedance matrix computed using the Rao-Wilton-Glisson basis function[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(10): 5324-5327.

Behnam Ghassemiparvin and Ayhan Altintas. Scattering from an impedance object at the edge of a perfectly conducting wedge[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(2): 852-861.

Ye Xiu-zhu, Chen Xu-dong, Yu Zhong, et al.. Simultaneous reconstruction of dielectric and perfectly conducting stutterers via T-matrix method[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(7): 3774-3781.

Cao Lei, Li Wei, and Hu Jun. A new T-matrix formulation for electromagnetic scattering by a radially multilayered gyroelectric sphere[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(2): 836-842.

Zhuromskyy O and Peschel U. T-matrix analysis of dipole waves on chains of dielectric particles[C]. 7th International Congress on Advanced Electromagnetic Materials in Microwaves and Optics-Metamaterials, Bordeaux, France, 2013: 268-270.

Tsang Leung and Chang Xin. Modeling of vias sharing the same antipad in planar waveguide with boundary integral equation and group T-matrix method[J]. IEEE Transactions on Components, Packaging and Manufacturing Technology, 2013, 3(2): 315-327.

Ozdemir N A, Ovejero D G, and Craeye C. On the relationship between multiple-scattering macro basis functions and Krylov subspace iterative methods[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(4): 2088-2098.

Desmal A and Ba c H. Shrinkage-thresholding enhanced born iterative method for solving 2D inverse electromagnetic scattering problem[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(7): 3878-3884.

Polewski M, Lech R, and Mazur J. Rigorous modal analysis of structures containing inhomogeneous dielectric cylinders[J]. IEEE Transactions on Microwave Theory and Techniques, 2004, 52(5): 1508-1516.

Kusiek A, Kowalczyk P, and Mazur J. Analysis of scattering from arbitrary conflguration of elliptical obstacles using T-matrix representation[J]. IET Microwaves, Antennas Propagation, 2008, 2(5): 434-441.

Adam Kusiek, Rafal Lech, and Jerzy Mazur. A new hybrid method for analysis of scattering from arbitrary conguration of cylindrical objects[J]. IEEE Transactions on Antennas and Propagation, 2008, 56(6): 1725-1733.
