基于稀疏孔徑的聯合稀疏約束干涉ISAR機動目標三維成像

張榆紅; 邢孟道; 徐剛

doi:10.11999/JEIT150125

基于稀疏孔徑的聯合稀疏約束干涉ISAR機動目標三維成像

doi: 10.11999/JEIT150125

計量
- 文章訪問數: 1335
- HTML全文瀏覽量: 126
- PDF下載量: 670
- 被引次數: 0
出版歷程
- 收稿日期: 2015-01-22
- 修回日期: 2015-04-14
- 刊出日期: 2015-09-19

Joint Sparsity Constraint Interferometric ISAR Imaging for 3-D Geometry of Maneuvering Targets with Sparse Apertures

摘要

摘要: InISAR系統能夠?qū)崿F(xiàn)對目標的3維幾何估計，更加有利于目標的分類和識別。同時多功能ISAR/InISAR系統針對的多是機動性很強的目標，在某些情況下對單個目標僅能獲取稀疏孔徑觀測，尤其是在目標存在機動特性的情況下，更是增加了ISAR成像的難度，這些對傳統的ISAR成像算法提出了挑戰。為了解決上述這些問題，該文針對機動目標提出一種基于稀疏孔徑的聯合稀疏約束InISAR 3維成像方法。對勻加速轉動的目標，回波的多普勒調制可以建模成線性調頻的形式，并用chirp-傅里葉字典來表征其機動性。接著將聯合的多通道InISAR 2維成像轉化為聯合稀疏約束的最優化求解問題，并用改進的OMP算法進行求解。然后利用各個通道估計的ISAR圖像和調頻參數實現對目標的3維幾何重構。相比于單通道獨立成像，聯合多通道稀疏約束成像能獲得更好的2維和3維成像結果。最后，進行實測數據實驗以驗證該文算法的有效性。
- 干涉逆合成孔徑雷達 /
- 機動目標 /
- 稀疏孔徑 /
- 聯合多通道成像 /
- 3D幾何模型
Abstract: Interferometric Inverse SAR (InISAR) is capable of acquiring three-dimensional image of the moving targets, which is much helpful to the target classification and identification. Meanwhile, multifunctional ISAR/InISAR system aims at maneuvering targets and only sparse aperture measurements are available for each target, which is a challenge to the conventional ISAR imaging algorithms. A joint sparsity-constraint InISAR 3-D imaging approaches is presented for maneuvering targets with sparse apertures. For a uniformly accelerated rotation target, the Doppler modulation in echo is formulated as chirp sensing code under a chirp-Fourier dictionary to represent the maneuverability. Then the joint multi-channel InISAR imaging approach is converted into a joint sparse constraint optimization. And a modified Orthogonal Matching Pursuit (OMP) algorithm is employed to solve the optimization. The 3-D target geometry is followed by using obtaining 2-D images and estimated chirp parameters. Finally, the experiment using measured data is performed to confirm the effectiveness of the proposed method.
- Interferometric Inverse SAR (InISAR) /
- Maneuvering targets /
- Sparse apertures /
- Joint multi-channel imaging /
- 3D geometry

HTML全文

參考文獻(21)

保錚, 邢孟道, 王彤. 雷達成像技術[M]. 北京: 電子工業出版社, 2005: 229-276.

李麗亞, 劉宏偉, 曹向海, 等. 基于InISAR像的目標識別方法[J]. 電子與信息學報, 2008, 30(9): 2089-2093.

Li Li-ya, Liu Hong-wei, Cao Xiang-hai, et al.. Radar automatic target recognition based on InISAR images[J]. Journal of Electronics Information Technology, 2008, 30(9): 2089-2093.

李飛, 糾博, 劉宏偉. 基于隨機霍夫變換的干涉ISAR橫向定標算法[J]. 電子與信息學報, 2013, 35(1): 49-55.

Li Fei, Jiu Bo, and Liu Hong-wei. A novel method of cross-range scaling interferometric ISAR based on randomized hough transform[J]. Journal of Electronics Information Technology, 2013, 35(1): 49-55.

Wang Gen-yuan, Xia Xiang-gen, and Chen Victor C. Three-dimensional ISAR imaging of maneuvering target using three receivers[J]. IEEE Transactions on Image Processing, 2001, 10(3): 436-447.

Zhang Qun, Yeo T S, Du Gan, et al.. Estimation of three-dimensional motion parameters in interferometric ISAR imaging[J]. IEEE Transactions on Geoscience and Remote Sensing, 2004, 42(2): 292-300.

Xu Gang, Xing Meng-dao, Zhang Lei, et al.. Sparse-apertures ISAR imaging and scaling for maneuvering targets[J]. IEEE Journal of Selected Topics in Applied Earth Observation and Remote Sensing, 2014, 7(7): 2942-2956.

Liu Ya-bo, Li N, and Wang R. Achieving high-quality three-dimensional InISAR imageries of maneuvering target via super-resolution ISAR imaging by exploiting sparseness[J]. IEEE Geoscience and Remote Sensing Letters, 2014, 11(4): 828-832.

徐剛, 楊磊, 張磊, 等. 一種加權最小熵的ISAR自聚焦算法[J]. 電子與信息學報, 2011, 33(8): 1809-1815.

Xu Gang, Yang Lei, Zhang Lei, et al.. Weighted minimum entropy autofocus algorithm for ISAR imaging[J]. Journal of Electronics Information Technology, 2011, 33(8): 1809-1815.

Xu Gang, Xing Meng-dao, and Zhang Lei. Bayesian inverse synthetic aperture radar imaging[J]. IEEE Geoscience and Remote Sensing Letters, 2011, 8(6): 1150-1154.

吳敏, 邢孟道, 張磊. 基于壓縮感知的二維聯合超分辨ISAR成像算法[J]. 電子與信息學報, 2014, 36(1): 187-193.

Wu Min, Xing Meng-dao, and Zhang Lei. Two dimensional Joint super-resolution ISAR imaging algorithm based on compressive sensing[J]. Journal of Electronics Information Technology, 2014, 36(1): 187-193.

Xia Xiang-gen. Discrete chirp-Fourier transform and its application to chirp rate estimation[J]. IEEE Transactions on Signal Processing, 2000, 48(11): 3122-3133.

Guo Xin, Sun H B, and Wang S L. Comments on discrete chirp-Fourier transform and its application to chirp rate estimation[J]. IEEE Transactions on Signal Processing, 2002, 50(12): 3115-3116.

Ramakrishnan N, Ertin E, and Moses R L. Enhancement of coupled multi-channel images using sparsity constraints[J]. IEEE Transactions on Image Processing, 2010, 19(8): 2115-2126.

Eldar Y and Rauhut H. Average case analysis of multichannel sparse recovery using convex relaxation[J]. IEEE Transactions on Information Theory, 2010, 56(1): 505-519.

Baraniuk R G, Cevher V, Duarte M F, et al.. Model-based compressive sensing[J]. IEEE Transactions on Information Theory, 2010, 56(4): 1982-2001.

陳倩倩, 徐剛, 李亞超, 等. 短孔徑ISAR方位定標[J]. 電子與信息學報, 2013, 35(8): 1854-1861.

Chen Qian-qian, Xu Gang, Li Ya-chao, et al.. Cross-range scaling for ISAR with short aperture data[J]. Journal of Electronics Information Technology, 2013, 35(8): 1854-1861.
