時空非均勻采樣下雙基地MIMO雷達收發角及多普勒頻率聯合估計方法
doi: 10.11999/JEIT141523
-
1.
(北方電子設備研究所 北京 100191) ②(內江師范學院工程技術學院 內江 641110)
基金項目:
四川省教育廳項目(13ZA0005)
Joint DOD-DOA and Doppler Frequency Estimation for Bistatic MIMO Radar under Condition of Temporal-spatial Nonuniform Sampling
-
1.
(Institute of North Electronic Equipment, Beijing 100191, China)
-
2.
(Engineering and Technology College, Neijiang Normal University, Neijiang 641110, China)
-
摘要: 該文針對發射陣列、接收陣列以及多級延遲器均為非均勻配置的雙基地MIMO雷達，提出基于時域和空域二次自由度擴展的發射角、接收角以及多普勒頻率估計的ESPRIT (Estimating Signal Via Rotational Invariance Techniques)新方法。該方法利用雙基地MIMO雷達特殊的方向矢量特點(矩陣的Khatri-Rao積形式)，對接收信號進行兩次行置換以及去冗余處理，實現了時域和空域孔徑自由度的二次擴展。然后對新數據進行時空滑窗處理，利用ESPRIT算法分別估計出目標的收發角以及多普勒頻率。理論和仿真結果表明：在相同陣元和延遲級數情況下，所提算法的估計性能優于四線性分解和多維ESPRIT算法，且能估計出更多的目標，此外，通過最小冗余配置，極大地降低了陣列和延遲器的配置需求，更利于實際工程應用。
-
關鍵詞:
- 雙基地MIMO雷達 /
- 時空非均勻結構 /
- 最小冗余陣列 /
- 二次自由度擴展 /
- 聯合估計
Abstract: A new ESPRIT (Estimating Signal Via Rotational Invariance Techniques) algorithm is proposed to estimate the joint DOD (Direction Of Departure), DOA (Direction Of Arrival) and Doppler frequency based on the second extension of degree of freedom in the time and space domain under the conditions of non-uniform configurations of transmitter-receiver arrays and multiple delays for bistatic MIMO radar. Firstly, based on the special characteristic of direction vector in MIMO radar, the second extension of degree of freedom both in the time and space domains is attained by performing the twice row permutations on the received data and deleting the redundant items operations. Then, the ESPRIT algorithm is utilized to estimate the DOD, DOA, and Doppler frequency after performing the temporal-spatial smoothing window processing to the new data. The simulation shows that when the same number of real elements is used in time and space domain, the parameter estimation performance of the proposed algorithm is better than those of the quadrilinear decomposition and multi-dimension ESPRIT algorithms. Moreover, by using of the minimum redundancy configuration, the redundant information in the arrays decreases and hence the requirements of the array elements and the delay device are reduced, so it is more convenient to the practical application. -
Dionysios S K and Athina P P. Matrix completion in collocated MIMO radar: recoverability, bounds theoretical guarantees[J]. IEEE Transactions on Signal Processing, 2014, 62(2): 309-321. 唐波, 張玉, 李科, 等. 雜波中MIMO雷達恒模波形及接收機聯合優化算法研究[J]. 電子學報, 2014, 42(9): 1705-1711. Tang Bo, Zhang Yu, Li Ke, et al.. Joint constant-envelope waveform and receiver design for MIMO radar in the presence of clutter [J]. Acta Electronica Sinica, 2014, 42(9): 1705-1711. Haimovich A M, Blum R S, Lenard J, et al.. MIMO radar with widely separated antennas[J]. IEEE Signal Processing Magazine, 2008, 25(1): 116-129. Chen Duo-fang, Chen Bai-xiao, and Qin Guo-dong. Angle estimation using ESPRIT in MIMO radar[J]. Electronics Letters, 2008, 44(12): 770-771. 孫中偉, 張小飛, 吳海浪, 等. L型陣列雙基地MIMO雷達的傳播算子多維角度估計[J]. 應用科學學報, 2014, 32(4): 57-64. Sun Zhong-wei, Zhang Xiao-fei, Wu Hai-lang, et al.. Multi-dimensional angle estimation in bistatic MIMO radar for L-shaped array with propagator method[J]. Journal of Applied Sciences, 2014, 32(4): 57-64. Chen Chen, Zhang Xiao-fei, and Ben De. Coherent angle estimation in bistatic multi-input multi-output radar using parallel profile with linear dependencies decomposition[J]. IET Radar, Sonar Navigation, 2013, 7(8): 867-874. 孫理, 朱曉華, 賀亞鵬, 等. 雙基地稀疏陣列MIMO雷達快速多目標定位方法[J]. 電子與信息學報, 2013, 35(5): 1142-1148. Sun Li, Zhu Xiao-hua, He Ya-peng, et al.. Fast multi-target localization with sparse array in bistatic MIMO radar[J]. Journal of Electronics Information Technology, 2013, 35(5): 1142-1148. 李小波, 梁浩, 崔琛. 基于四元數和增廣矩陣束的MIMO雷達角度估計算法[J]. 數據采集與處理, 2014, 29(4): 579-583. Li Xiao-bo, Liang Hao, and Cui Chen. Angle estimation in bistatic MIMO radar based on quaternion and MEMP[J]. Journal of Data Acquisition and Processing, 2014, 29(4): 579-583. 鄭志東, 張劍云, 楊瑛. 基于發射波束域-平行因子分析的MIMO雷達收發角度估計[J]. 電子與信息學報, 2011, 33(12): 2875-2880. Zheng Zhi-dong, Zhang Jian-yun, and Yang Ying. Joint DOD-DOA estimation of MIMO radar based on transmit beamspace-PARAFAC[J]. Journal of Electronics Information Technology, 2011, 33(12): 2875-2880. Cao Y H. Joint estimation of angle and Doppler frequency for bistatic MIMO radar[J]. Electronics Letters, 2010, 46(2): 170-172. 劉帥, 張弓, 劉文波. 基于時空結構的雙基地MIMO雷達多維參數聯合估計[J]. 航空學報, 2010, 31(6): 1196-1203. Liu Shuai, Zhang Gong, and Liu Wen-bo. Multi-dimensional parameter joint estimation of bistatic MIMO radars based on temporal-spatial structure[J]. Acta Aeronautica et Astronautica Sinica, 2010, 31(6): 1196-1203. 李建峰, 張小飛. 基于四線性分解的雙基地MIMO雷達的角度和多普勒頻率聯合估計[J]. 航空學報, 2012, 33(8): 1474-1482. Li Jian-feng and Zhang Xiao-fei. Joint estimation of angle and Doppler frequency in bistatic MIMO radar based on quadrilinear decomposition[J]. Acta Aeronautica et Astronautica Sinica, 2012, 33(8): 1474-1482. Pal P and Vaidynanthan P P. Nested arrays: a novel approach to array processing with enhanced degrees of freedom[J]. IEEE Transactions on Signal Processing, 2010, 58(8): 4176-4181. Moffer A T. Minimum-redundancy linear arrays[J]. IEEE Transactions on Antennas and Propagation, 1968, 16(2): 172-175. Liu J and Liu X Q. An eigenvector-based approach for multidimensional frequency estimation with improved identifiability[J]. IEEE Transactions on Signal Processing, 2013, 54(12): 4543-4556. -
