Height Measurement Algorithm of Meter-wave Radar Network Based on Virtual Plane
-
摘要: 隨著反隱身技術的發展，米波雷達憑借其反隱身、反輻射導彈方面的天然優勢，再度進入科學界的視野。但米波雷達在探測低仰角目標過程中受多路徑效應影響嚴重，導致測高結果易出現較大偏差，無法滿足實際需要。而組網雷達數據融合技術的發展為此問題找到了一個解決辦法。該文采用組網雷達數據融合技術，僅利用米波雷達測得的距離和方位信息實現了目標的3維定位，從而解決米波雷達測高困難的問題?？紤]地球曲率的影響。該文所提出的米波組網雷達測高算法利用大地坐標變換、坐標系變換和數據變換，把各雷達數據統一到一個合理的工作平臺，即虛擬平面上，在該平面上對目標進行測高計算。對極小誤差法加以改進，采用分辨率不高，但數據穩定性好的方位角信息確定算法的搜索范圍；應用分辨率較高的目標距離信息來獲取最終的目標經度、緯度、海拔高度估值。由于地面強反射的原因，目標的距離估值有些時候是不準確的，該文設立了置信度判決準則以驗證定位的有效性。通過仿真驗證，該算法具有較好的測高精度，可作為組網雷達行之有效的測高方法。
-
關鍵詞:
- 米波雷達 /
- 組網雷達 /
- 高度測量 /
- 虛擬平面 /
- 極小誤差法
Abstract: With development of anti-stealth technology, meter-wave radar comes into sight of scientific community again due to its natural superiority of anti-stealth and anti-radiation missile. But as strongly influenced by multi- path effect in process of detecting target with low elevation angle, meter-wave radar may obtain a measured height with large deviation that unable to meet actual need. However, the development of data fusion technology in radar network finds a solution to this problem. This paper uses data fusion technology of radar network to realize three-dimensional positioning of target only with distance and azimuth information measured by meter-wave radar, so that the problem of height measurement in meter-wave radar can be well solved. In consideration of effect of earth curvature, the proposed height measurement algorithm of meter-wave radar network utilizes geodetic coordinate transformation, coordinate system transformations, and data transformation to unite all radars data into one reasonable work platform, namely virtual plane. Height measurement is conducted to target on this plane. Azimuth angle information with not high resolution ratio but good data stability is used to determine hunting zone of algorithm so as to improve minimum error method. The target distance information with high resolution ratio is used to obtain final longitude, latitude and altitude estimate of target. Sometimes target distance estimate may be inaccurate as a result of strong reflection on earth surface, according to which a confidence judgment criterion is established to verify availability of positioning. Through the simulation analysis, the proposed algorithm is verified to obtain a good accuracy in height measurement and can be regarded as an effective method in height measurement for radar network.-
Key words:
- Meter-wave radar /
- Radar network /
- Height measurement /
- Virtual plane /
- Minimum error method
-
李靜明, 丁建江. 雷達低仰角下復雜地形反射特性研究[J]. 火控雷達技術, 2013, 42(3): 25-27, 38. Li Jing-ming and Ding Jian-jiang. Study on complex terrain reflection characteristics at low elevation of radar[J]. Fire Control Radar Technology, 2013, 42(3): 25-27, 38. 趙英俊, 李榮鋒, 王永良, 等. 基于主瓣多徑干擾抑制的米波雷達測角方法[J]. 華中科技大學學報(自然科學版), 2013, 41(4): 51-55. Zhao Ying-jun, Li Rong-feng, Wang Yong-liang, et al.. Angles measurement of meter-wave radars by multipath jamming suppression[J]. Journal of Huazhong University of Science and Technology (Netural Science Edition), 2013, 41(4): 51-55. Chen Bai-xiao, Zhao Guang-hui, and Zhang Shou-hong. Altitude measurement based on beam split and frequency diversity in VHF radar[J]. IEEE Transactions on Aerospace and Electronic Systems, 2010, 46(1): 3-13. 朱偉, 鄭軼松, 陳伯孝. 約束MUSIC算法在米波雷達低仰角測高中的應用[J]. 安徽大學學報(自然科學版), 2014, 38(4): 59-65. Zhu Wei, Zheng Yi-song, and Chen Bai-xiao. Application of constrained MUSIC to the low-angle altitude measurement for VHF radar[J]. Journal of Anhui University(Natural Science Edition), 2014, 38(4): 59-65. 吳向東, 馬侖, 梁中華. 基于波束域的米波雷達低仰角波達方向估計[J]. 電波科學學報, DOI: 10.13443/j.cjors. 2013103101. Wu Xiang-dong, Ma Lun, and Liang Zhong-hua. Estimation of direction-of-arrival for meter-wave radar based on beam-space at low-angle environment[J]. Chinese Journal of Radio Science, DOI: 10.13443/j.cjors. 2013103101. 楊廣玉, 楊雪亞. 基于RELAX的米波雷達測高方法[J]. 科技信息, 2014(1): 75, 101. Yang Guang-yu and Yang Xue-ya. Height measurement algorithm of meter-wave radar based on RELAX[J]. Science Technology Information, 2014(1): 75, 101. 朱偉. 米波數字陣列雷達低仰角測高方法研究[D]. [博士論文], 西安電子科技大學, 2013. Zhu Wei. Study on low-angle altitude measurement in VHF Radar[D]. [Ph.D. dissertation], Xidian University, 2013. 孫仲康, 周一宇, 何黎星. 單多基地有源無源定位技術[M]. 北京: 國防工業出版社, 1996: 118-131. Sun Zhong-kang, Zhou Yi-yu, and He Li-xing. The Technology of Active and Passive Positioning of Monostatic or Multistatic Radars[M]. Beijing: National Defence Industry Press, 1996: 118-131. 趙振山, 楊萬海. 組網雷達定位優化算法[J]. 雷達與對抗, 2002(3): 1-4, 11. Zhao Zhen-shan and Yang Wan-hai. Optimal locating algorithm in networking radar[J]. Radar ECM, 2002(3): 1-4, 11. Bowring B R. Transformation form spatial to geographical coordinates[J]. Survey Review, 1976, 23(181): 323-327. Bowring B R. The accuracy of geodetic latitude and height equations[J]. Survey Review, 1985, 28(181): 202-206. Schmidt R O. A new approach to geometry of range difference location[J]. ?IEEE Transactions on Aerospace and Electronic Systems, 1972, 18(6): 821-835. 黃喜軍, 韓傳久, 張彤. 組網雷達距離信息實現目標3維定位[J]. 火力與指揮控制, 2005, 30(S1): 121-122. Huang Xi-jun, Han Chuan-jiu, and Zhang Tong. Three- dimension target location using range information measured by networking radar[J]. Fire Control and Command Control, 2005, 30(S1): 121-122. -
