基于Chirp_z變換與方位變標地球同步軌道SAR成像算法
doi: 10.11999/JEIT141491
-
2.
(西北工業大學電子信息學院 西安 710129) ②(中國空間技術研究院西安分院 西安 710100)
Imaging Algorithm for Geosynchronous Orbit SAR Based on Chirp_z Transform and Azimuth Scaling
-
2.
(School of Electronics and Information, Northwestern Polytechnical University, Xi&rsquo
-
摘要: 針對地球同步軌道合成孔徑雷達(GEO SAR)成像距離向處理復雜，方位向空變性強問題，該文提出一種基于Chirp_z變換與方位變標的成像算法。首先在回波模型中考慮停-走-停假設帶來的相位誤差，然后給出目標點的斜距表達式，并利用泰勒級數對斜距進行了高階展開，通過級數反演法得到信號頻譜表達式，利用高效的Chirp_z變換校正距離走動，簡化距離向處理，利用改進的變標因子校正方位向信號一次，二次，三次展開項系數線性時變性，并在方位頻域內補償變標操作引入的相位誤差。仿真結果表明該算法能夠?qū)崿F(xiàn)地球同步軌道SAR聚集成像。
-
關鍵詞:
- 地球同步軌道合成孔徑雷達 /
- 成像算法 /
- Chirp_z變換 /
- 方位變標
Abstract: Aiming at the problem of complex range processing and strong azimuth variant in GEosynchronous Orbit SAR (GEO SAR) imaging processing, an imaging algorithm based on Chirp_z transform and the azimuth scaling is proposed. Firstly, the stop-go-stop phase error is considered in the echo model, and then the slant distance expression which is expanded using the Taylor series is given. After that, a series of inversion method is used to get the signal spectrum expression. In order to simplifying the imaging processing at range direction, the Chirp_z transform is used to correct the range walk. And then, an improved scale factor is used to correct the linear time-varying coefficient of signal expand included the first order, the second order and the three order. The phase error introduced by scaling operation is compensated in frequency domain. Finally, the simulation results show that the algorithm can realize geosynchronous orbit SAR imaging. -
Wu Zhou-ting,?Huang Li-jia, Hu Dong-hui,et al.. Azimuth resolution analysis in geosynchronous SAR with azimuth variance property[J]. Electronics Letters, 2014, 50(6): 464-466 Hobbs S E, Snapir B, Corstanje R, et al.. Simulation of geosynchronous radar and atmospheric phase compensation constraints[C]. Proceedings of the IET International Radar Conference, Xian, China, 2013: 1-6. Hu Cheng, Long Teng, Liu Zhi-peng, et al.. An improved frequency domain focusing method in geosynchronous SAR[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(9): 5514-5528. Zhao Bing-ji, Qi Xiang-yang, Song Hong-jun, et al.. An accurate range model based on the fourth-order doppler parameters for geosynchronous SAR[J]. IEEE Transactions on Geoscience and Remote Sensing Letters, 2014, 11(1): 205-209. Bao Min and Xing Meng-dao. Chirp scaling algorithm for GEO SAR based on fourth-order range equation[J]. Electronics Letters, 2012, 48(1): 56-57. Hu Cheng, Liu Zhi-peng, and Long Teng. An improved CS algorithm based on the curved trajectory in geosynchronous SAR[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2012, 5(3): 795-808. Wu Xiu, Zhang Shun-sheng, Li Jing. et al.. Geosynchronous SAR image formation based on advanced hyperbolic range equation[C]. Proceedings of IEEE Geoscience and Remote Sensing Symposium (IGARSS), Munich, Germany, 2012: 4042-4045. Sun Guang-cai, Xing Meng-dao, Wang Yong, et al.. A 2-D space-variant chirp scaling algorithm based on the RCM equalization and subband synthesis to process geosynchronous SAR data[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(8): 4868-4880. Li Zhuo, Li Chun-sheng, Yu Ze, et al.. Back projection algorithm for high resolution GEO-SAR image formation[C]. Proceedings of IEEE Geoscience and Remote Sensing Symposium (IGARSS), Vancouver, Canada, 2011: 336-339. Hobbs S, Mitchell C, Forte B, et al.. System design for geosynchronous synthetic aperture radar missions[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(12): 7750-7763. Ruiz-Rodon J, Broquetas A, Makhoul E, et al.. Nearly zero inclination geosynchronous SAR mission analysis with long integration time for earth observation[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(10): 6379-6391. 黃麗佳, 胡東輝, 丁赤飚. 中高軌道SAR信號建模和成像方法研究[J]. 國外電子測量技術, 2011, 30(6): 21-27. Huang Li-jia, Hu Dong-hui, and Ding Chi-biao. Study on signal modeling and imaging approach for medium- earth-orbit SAR[J]. Foreign Electronic Measurement Technology,?2011, 30(6): 21-27. 周鵬, 周松, 熊濤等. 基于級數反演的彈載SAR下降段CZT成像算法[J]. 電子與信息學報, 2010, 32(12): 2861-2867. Zhou Peng, Zhou Song, Xiong Tao, et al.. A chirp-z transform imaging algorithm for missile-borne SAR with diving maneuver based on the method of series reversion[J]. Journal of Electronics Information Technology, 2010, 32(12): 2861-2867. -
