雙向中繼系統用戶聯合預編碼與檢測算法研究
doi: 10.11999/JEIT141455
基金項目:
國家自然科學基金(61179018, 41476089)和泰山學者建設工程專項經費資助課題
Research on Users Joint Precoding and Detection in Two-way Relay Systems
-
摘要: 雙向中繼協同通信系統的兩用戶節點通過中繼節點相互交換信息，顯示了其在頻譜效率上的優勢。在系統裝備多天線的情況下，為進一步改善誤比特率性能，論文提出一種基于格規約算法的用戶聯合預編碼與檢測算法。該算法通過一次復數域格規約處理來提高信道增益矩陣的正交性，預編碼和檢測算法聯合應用處理后的矩陣，中繼節點僅需要對接收信號進行求模運算和放大轉發，算法的復雜度主要集中在兩用戶節點上。仿真結果顯示：相比于傳統的預編碼和檢測算法，用戶聯合預編碼與檢測算法在計算復雜度僅增加了對信道增益矩陣一次格規約計算的前提下，可顯著降低系統的誤比特率，提高分集增益，具有工程實用價值。Abstract: Two-way relay cooperative communication system demonstrates significant gain in spectral efficiency when two user nodes exchange information via a relay node. For improving the Bit Error Rate (BER) performance, a joint precoding and detection algorithm is proposed based on Lattice Reduction (LR) when all the nodes equipped with multiple antennas. The proposed algorithm modifies the channel gain matrix into more orthogonal matrix by the complex lattice reduction. Precoding and detection algorithms are combined to apply the modified matrix. The relay node processes the receiving signal by simple modulo operation and amplification. The main complexity of the algorithm is in the two user nodes. The simulation evaluations show that, the computational complexity of the algorithm is increasing just because the channel gain matrix is modified by lattice reduction. The proposed joint precoding and detection algorithm can significantly improve the performance of BER and achieve full diversity, hence it is applicable to engineering.
-
Key words:
- Cooperative communication /
- Two-way relaying /
- Lattice Reduction (LR) /
- Precoding /
- Detection
-
Jianhua M, Meixia T, and Yuan L. Secure beamforming for MIMO two-way communications with an untrusted relay[J]. IEEE Transactions on Signal Processing, 2014, 62(9): 2185-2199. 吉曉東, 鄭寶玉, 崔景伍. 不對稱雙向中繼信道中的再生雙向中繼選擇及功率分配[J]. 電子與信息學報, 2013, 35(7): 1707-1712. Ji Xiao-dong, Zheng Bao-yu, and Cui Jing-wu. Opportunistic relaying and power allocation for bidirectional regenerative relaying in asymmetric two-way relay channels[J]. Journal of Electronics Information Technology, 2013, 35(7): 1707-1712. 芮國勝, 王林, 張洋, 等. 分布式雙向中繼選擇算法及用戶功率分配[J]. 通信學報, 2014, 35(5): 1-7. Rui G S, Wang L, Zhang Y, et al.. Distributed two-way relay selection scheme and users power allocation[J]. Journal on Communications, 2014, 35(5): 1-7. Rankov B and Wittneben A. Spectral efficient protocols for halfduplex fading relay channels[J]. IEEE Journal on Selected Areas in Communications, 2007, 25(2): 379-389. Wooseok N, Chung Sae-young, and Lee Y H. Capacity bounds for two-way relay channels[C]. IEEE International Zurich Seminar on Digital Object Identifier. Zurich, Switzerland, 2008: 144-147. 趙睿, 傅友華, 李春國, 等. 多天線雙向中繼系統中的中繼處理與資源分配策略[J]. 電子與信息學報, 2010, 32(4): 763-769. Zhao Rui, Fu You-hua, Li Chun-guo, et al.. Relay processing and resource allocation strategies for multi-antenna two-way relay system[J]. Journal of Electronics Information Technology, 2010, 32(4): 763-769. Sanguinetti L, D'Amico A A, and Rong Y. A tutorial on the optimization of amplify-and-forward MIMO relay systems[J]. IEEE Journal on Selected Areas in Communications, 2012, 30(8): 1331-1346. Song C, Lee K-J, and Lee I. MMSE-based MIMO cooperative relaying systems: closed-form designs and outage behavior[J]. IEEE Journal on Selected Areas in Communications, 2012, 30(8): 1390-1401. Wang J, Wang Y, Gui X, et al.. Robust relay precoding design for two way relay systems with delayed and limited feedback[J]. IEEE Communications Letters, 2013, 17(3): 689-692. Wang R and Tao M. Joint source and relay precoding designs for MIMO two-way relaying based on MSE criterion[J]. IEEE Transactions on Signal Processing, 2012, 6(3): 13521365. Kossel M, Toifl T, and Francese P A. A 10 Gb/s 8-Tap 6b 2-PAM/4-PAM Tomlinson-Harashima precoding transmitter for future memory-link applications in 22-nm SOI CMOS[J]. IEEE Journal of Solid-State Circuits, 2013, 48(12): 3268-3284. Wbben D, Seethaler D, and Jaldn J. Lattice reduction[J]. IEEE Signal Processing Magazine, 2011, 50(5): 70-91. Agrell E, Eriksson T, Vardy A, et al.. Closest point search in lattices[J]. IEEE Transactions on Information Theory, 2002, 48(8): 22012214. Senning C, Bruderer L, and Hunziker J. A lattice reduction- aided MIMO channel equalizer in 90 nm CMOS achieving 720 Mb/s[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2014, 61(6): 1860-1871. Hung Ganying, Ling Cong, and Ho Mowwai. Complex lattice reduction algorithm for low-complexity full-diversity MIMO detection[J]. IEEE Transactions on Signal Processing, 2009, 57(7): 2701-2710. Yang Shao-hua and Qin Da-hua. Improved maximum likelihood sync mark detection for magnetic recording channels[J]. IEEE Transactions on Magnetics, 2013, 49(7): 3691-3694. Liu F, Jiang L, and He C. Advanced joint transceiver design for block diagonal geometric mean decomposition based multiuser MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2010, 59(2): 692-703. -
