面向AIC結構的FPGA映射工具
doi: 10.11999/JEIT141403
-
2.
(中國科學院電子學研究所可編程芯片與系統研究室 北京 100190) ②(中國科學院大學 北京 100049)
基金項目:
國家自然科學基金(61404140, 61271149, 61106033)資助課題
Mapper for AIC-based FPGAs
-
2.
(System on Programmable Chip Research Department, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
-
摘要: 探索新的現場可編程門陣列(FPGA)邏輯單元結構一直是FPGA結構研究的重點方向，與非邏輯錐(AIC)作為一種新的邏輯結構成為FPGA新結構的希望。然而實現高效且靈活的映射工具同樣是研究FPGA新結構中的重點環節。該文實現了一個面向AIC結構的FPGA映射工具，與當前映射工具相比，具有更高的靈活性，能夠支持AIC結構參數的調節，輔助支持進行AIC單元結構的探索改進。同時，該文提出的AIC映射工具與原工具相比，面積指標提高了33%~36%。
-
關鍵詞:
- 現場可編程門陣列 /
- 與非邏輯錐 /
- 映射
Abstract: Exploring a new logic element of Field Programmable Gate Array (FPGA) is always a key field in FPGAs research, while And-Inverter Cones (AIC) is the most promising one. Implementing a highly-efficient and highly-flexible mapping tool is also an important part of exploring new FPGA architecture. In this paper, a new mapper for AIC-based FPGA is implemented. Compared with an existing mapper, the new mapper has much higher flexibility, and supports adjustments of AICs architectural parameters to assit the design space exploration of AIC. Meanwhile, the new mapper provides area results 33%~36% better than the original mapper. -
Ian K and Rose J. Measuring the gap between FPGAs and ASICs[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2007, 26(2): 271-285. Ngai T, Rose J, and Wilton S. An SRAM programmable field-configurable memory[C]. Proceedings of the IEEE Custom Integrated Circuits Conference, Santa Clara, CA, 1995: 499-502. Rui Jia, Lin Y, Guo Z, et al.. A survey of open source processors for FPGAs[C].?IEEE International Conference on Field Programmable Logic and Applications (FPL), Munich, 2014: 521-526. Hutton M, Schleicher J, Lewis D, et al.. Improving FPGA performance and area using an adaptive logic module [C].?IEEE International Conference on Field Programmable Logic and Applications (FPL), Belgium, 2004: 135-144. Lewis D, Ahmed E, Baeckler G, et al.. The stratix II logic and routing architecture[C]. Proceedings of the 2005 ACM/ SIGDA 13th ACM International Symposium on Field- Programmable Gate Grrays, Monterey, 2005: 14-20. Jiang Z, Lin Y, Yang L, et al.. Exploring architecture parameters for dual-output LUT based FPGAs[C]. IEEE International Conference on Field Programmable Logic and Applications (FPL), Munich, 2014: 436-441. Parandeh-Afshar H, Benbihi H, Novo D, et al.. Rethinking FPGAs: elude the flexibility excess of LUTs with and-inverter cones[C]. Proceedings of the ACM/SIGDA International Symposium on Field Programmable Gate Arrays, Monterey, 2012: 119-128. Parandeh-Afshar H, Zgheib G, Novo D, et al.. Shadow and-inverter cones[C]. IEEE International Conference on Field Programmable Logic and Applications (FPL), Porto, 2013: 1-4. Zgheib G, Yang L, Huang Z, et al.. Revisiting and-inverter cones[C]. Proceedings of the 2014 ACM/SIGDA International Symposium on Field-Programmable Gate Arrays, ACM, Monterey, 2014: 45-54. Brayton R and Mishchenko A. ABC: an academic industrial- strength verification tool[C]. Computer Aided Verification, Edinburgh, 2010: 24-40. Mishchenko A,? Cho S, Chatterjee S, et al.. Combinational and sequential mapping with priority cuts[C].?IEEE International Conference on Computer-Aided Design, San Jose, 2007: 354-361. Cong J, Wu C, and Ding Y. Cut ranking and pruning: enabling a general and efficient FPGA mapping solution [C].?Proceedings of the 1999 ACM/SIGDA Seventh International Symposium on Field Programmable Gate Grrays, Monterey, 1999: 29-35. Luu J,? Goeders J, Wainberg M, et al.. VTR 7.0: Next generation architecture and CAD system for FPGAs[J]. ACM Transactions on Reconfigurable Technology and Systems (TRETS), 2014,?7(2): DOI: 10.1145/2617593. -
