Analysis and Design of a New 22 Tapered Finline Array for Spatial Power Combining
-
摘要: 漸變鰭線陣在空間功率合成放大器中具有重要的應用價值。該文簡化漸變鰭線陣的模型，將漸變鰭線陣設計等效為T(mén)E模式波阻抗的漸變阻抗變換，采用譜域?qū)Ъ{法計算漸變鰭線陣的傳播常數，依據小反射理論，提出一種新型基于Hecken形式的緊湊、寬帶漸變鰭線陣。利用高頻仿真軟件HFSS進行優化仿真設計，通過引入槽線微帶過渡電路，實際加工了X波段22鰭線陣，背靠背測試結果表明：在X波段(8~12 GHz)內，反射系數小于-12 dB，插入損耗小于1 dB，實測結果與理論計算吻合。該文系統地給出漸變鰭線陣設計優化的理論計算和仿真方法，對基于波導內空間功率合成模塊設計具有指導意義，具有良好的工程應用前景。
-
關鍵詞:
- 漸變鰭線陣 /
- 波導內空間功率合成 /
- Hecken曲線 /
- 譜域?qū)Ъ{法
Abstract: Tapered finline array plays an important role in waveguide-based spatial power combiner. This paper presents a simplified model of tapered finline array by taking it as a tapered TE mode wave impedance transformer. The spectral domain admittance method is applied for deriving the propagation constant. Based on the small reflection theory, a new compact and broadband Hecken finline taper array is proposed. The structure is simulated and optimized by HFSS. By introducing slotline-to-microstrip line transition, the finline array in X-band is manufactured. The back-to-back test results of optimal 22 Hecken finline taper arrays consistent with theoretical values show that the return coefficient is less than -12 dB and the insert loss is less than 1 dB in X-band (8~12 GHz). This paper presents the method of analysis and design of the finline array, and provides a guideline for designing the waveguide-based power combiner. It serves as a promising circuit for power combining. -
