一種應用于斜視聚束模式的改進極坐標格式成像算法
doi: 10.11999/JEIT140564
基金項目:
航空基金(20110181004)和中央高?；究蒲袠I(yè)務費(K5051202016)資助課題
A Modified Polar Format Algorithm Applied to Squinted Spotlight SAR Imaging
-
摘要: 極坐標格式算法(Polar Format Algorithm, PFA)通常應用于正側視聚束SAR成像，當PFA應用斜視聚束時，傳統沿視線插值(Line Of Sight Interpolation, LOSI)PFA方法會導致方位頻譜非等間隔采樣。該文針對上述問題提出一種新的方位頻譜插值方法，根據斜視聚束的幾何模型可以得到方位頻譜精確的插值形式，從而實現對方位頻譜等間隔重采樣。在獲得了均勻的頻譜后進行2維逆傅里葉變換，便可以得到大范圍的斜視聚束場景。為了驗證該文算法的有效性，進行了實驗仿真及實測數據驗證，該方法與傳統插值的方法進行比較，能夠增大斜視聚束場景范圍。
-
關鍵詞:
- 斜視聚束SAR /
- 極坐標格式算法 /
- 沿視線插值 /
- 方位重采樣 /
- 非均勻采樣
Abstract: For broadside spotlight Synthetic Aperture Radar (SAR) imaging, Polar Format Algorithm (PFA) is applied widely as a kind of general interpolation algorithm. When PFA is applied to the squinted spotlight, coordinate rotation causes azimuth spectrum uniformly resampled. A new method of interpolation for azimuth spectrum is proposed in this paper and the accurate form of azimuth spectrum interpolation is given according to the geometry of squinted spotlight. Azimuth spectrum is resampled according to the accurate form of interpolation and uniform azimuth spectrum is obtained. Then, two-dimension IFFT is implemented and high resolution squinted spotlight image is obtained. In order to validate the effectiveness, simulation and real data are processed by the proposed method. Compared with traditional interpolation method, the scope of well-focused image is increased. -
