基于線陣的MIMO-ISAR二維成像方法
doi: 10.11999/JEIT140529
基金項目:
國家自然科學基金(61382166)和陜西省自然科學基礎研究計劃(2014JM8308)資助課題
Two-dimensional Imaging Using MIMO Radar and ISAR Technique Based on Linear Array
-
摘要: 針對多輸入多輸出逆合成孔徑雷達(MIMO-ISAR)成像中空-時陣列非均勻造成的成像數據不均勻，該文基于線陣建立了目標空-時回波信號模型，經過推導，提出一種相同距離單元橫向聚焦的成像方法。該方法首先進行距離補償，將空時分布的距離像對齊至目標初始位置；然后構建相位因子，補償非關心方向運動引起的相位變化；最后對相同距離單元數據沿橫向相干疊加，實現橫向聚焦。該算法不受陣列形式的限制，無需數據均勻化處理，而且能夠橫向定標，仿真驗證了該方法的有效性。
-
關鍵詞:
- 多輸入多輸出逆合成孔徑雷達成像 /
- 距離補償 /
- 橫向聚焦
Abstract: In view of the uneven imaging data caused by the uneven space-time array in the MIMO-ISAR imaging, the echo signal model of a target is established based on a linear array, an imaging algorithm that focuses on the cross-range direction following range unit is proposed. The range compensation is applied firstly, which can make range profiles that distribute in the space-time domain align at the initial position of target. Then phase changes caused by motion in unconcerned direction are compensated. Finally, the range profiles are focused in the cross-range direction following range unit by coherent addition. The algorithm is not restricted by the structure of the array and the processing of uniformity is not needed. In addition, it can determine the ISAR image scale in the cross-range direction. The simulation results verify the validity of the proposed algorithm. -
