加載矩形波導中的并矢格林函數及其應用
DYADIC GREEN S FUNCTION FOR LOADED RECTANGULAR WAVEGUIDE AND ITS APPLICATION
-
摘要: 本文用鏡像法推導出加載矩形波導中的并矢格林函數。在具體計算中,由于應用積分變換以及將多重?zé)o窮求和化為單一無窮和,極大地簡化了計算,節省了計算時間。作為并矢格林函數應用的例子,給出了位于加載波導寬邊上的金屬球散射場的矩量解.計算結果與實驗和文獻的結果吻合很好。這種方法還能推廣到其它波導。
-
關鍵詞:
- 加載波導; 積分變換; 并矢格林函數
Abstract: This paper presents a method to derive the dyadic Green s function of a loaded rectangular waveguide by image method. In the calculation of the DGF, it is simplified by using the integral transformation and replacing the multi-infinite summation with a single one. As an example of the DGF s application, the scattering field calculation of a metal sphere resting on the broad wall of the loaded rectangular waveguide is given by mo ney ethod. Results of calculations agree well with both data of experiments and those published. -
C T.Tai, Proc. IEEE, 61(1973), 480-481.[2]Y.Rahmaf-Samii, IEEE Trans. on MTT, MTT-23(1975), 762-765.[3]J. J. H. Way, IEEE Trans. on MTT, MTT-26(1978), 457-462.[4]Z. Shanjie, Hu Xiaoxin, Acta Electronica Sinica, 11(1983)3, 104--108.[5]J. A. Grzesik, IEEE Trans. on AP, AP-32(1982), 204-206.[6]喻東遠, 空心及加載矩形波導中金屬球散射場的研究,成都電訊工程學院,博士論文,1986.[7]Y. L. Chow, K. D. Srivastava, J. of Electrostatic, 11(1982), 167-178.[8]C. T. Tai.[J].Dyadic Greens Function in Electromagnetic Theory, Scranton, PA: International Texibook, ch..1971,:-[9]A. Papoulis, The Fourier Integral and Its Applications, McGraw-Hill Book Company Icn,1962, pp.47-49.[10]R. F. Harrington, Field Computation by Moment Method, New York, MacMillan, 1968.[11]P. I. Somlo, D. L. Hollway, Electronic Letters, 18(1972), 507-508. -
