圓形外導體-復雜形狀內導體同軸傳輸線特性阻抗的計算

潘生根

潘生根. 圓形外導體-復雜形狀內導體同軸傳輸線特性阻抗的計算[J]. 電子與信息學報, 1988, 10(2): 180-185.
引用本文: 潘生根. 圓形外導體-復雜形狀內導體同軸傳輸線特性阻抗的計算[J]. 電子與信息學報, 1988, 10(2): 180-185.
Pan Shenggen. THE CHARACTERISTIC IMPEDANCE OF THE COAXIAL SYSTEM CONSISTING OF A CIRCULAR OUTER CONDUCTOR AND AN IRREGULAR INNER CONDUCTOR[J]. Journal of Electronics & Information Technology, 1988, 10(2): 180-185.
Citation: Pan Shenggen. THE CHARACTERISTIC IMPEDANCE OF THE COAXIAL SYSTEM CONSISTING OF A CIRCULAR OUTER CONDUCTOR AND AN IRREGULAR INNER CONDUCTOR[J]. Journal of Electronics & Information Technology, 1988, 10(2): 180-185.

圓形外導體-復雜形狀內導體同軸傳輸線特性阻抗的計算

THE CHARACTERISTIC IMPEDANCE OF THE COAXIAL SYSTEM CONSISTING OF A CIRCULAR OUTER CONDUCTOR AND AN IRREGULAR INNER CONDUCTOR

  • 摘要: 本文由Meleontiev方法將任意復雜形狀的單連通區域的外部變換為單位圓的外部,利用多項式變換函數的性質和復雜形狀內導體邊界的等效圓半徑變化的一般規律,給出了具有圓形外導體-復雜形狀內導體一類傳輸線的解。通過與文獻中準確值的比較,證實了本文方法的準確性和實用性。
    Abstract: In this paper, the transformation of an exterior of a simply-connected region into an exterior of a unit circle is made by Melentiev s method and a formula is presented for determining the characteristic impedance of a coaxial transmission line consisting of a circular outer conductor and an irregular inner conductor. The validity of the formula is confirmed by numerical results.
    • HTML全文
  • 潘生根,中國科學,A輯,1986年第9期,第999頁.[2]林為干,微波理論與技術,科學出版社,1979年.[3]P. Laura, L. Luisoni, IEEE Trans. on MTT, MTT-25(1977), 160[4]W. Lin(林為干),IEEE Trans. on MTT, MTT-29(1981), 1981.[5]T. Seshadri, K. Rajaiah, Proc. IEEE, 70(1982), 82.[6]L. Kantorokitch, V. Krylov, Approximate Methods of Higher Analysis, Interscience Publishers, Inc., 1958.[7]K. Tsuruta and R. Terakado, IEEE Trans. on MTT, MTT-28(1980), 147.[8]S. G. Pan(潘-生根), IEEE Trans. on MTT, MTT-35(1987), 61.
  • 加載中
計量
  • 文章訪問數:  2618
  • HTML全文瀏覽量:  189
  • PDF下載量:  469
  • 被引次數: 0
出版歷程
  • 收稿日期:  1986-07-25
  • 修回日期:  1987-01-26
  • 刊出日期:  1988-03-19
