波導E面金屬片濾波器的優化設計
AN OPTIMIZATION DESIGN OF WAVEGUIDE E-PLANE METAL INSERT FILTERS
-
摘要: 本文采用模式展開方法,導出了波導E面金屬片濾波器的散射參量,進而編寫了濾波器優化設計程序,設計、制造和測試了一個長三厘米濾波器,實驗結果和理論結果符合得很好。本文方法考慮了高次模式通過諧振腔發生的耦合,設計的濾波器特性比較理想,在頻率的低端和高端阻帶衰減都較大,所以比采用變分原理導出等效網絡參數然后進行綜合設計的方法優越。
-
關鍵詞:
- 微波濾波器; E面濾波器; CAD
Abstract: An optimization design theory and algorithm have been developed for waveguide E-plane metal insert filters. The immediate higher order mode coupling in resonator between the discontinuities, which reduces the stop band attenuation for higher frequencies is taken into account. An optimized design filter has been fabricated and tested in low X-band. Good agreement with design has been obtained. -
Y. Konishi and K. Uenakada, IEEE Trans on MTT, MTT-22(1974), 869.[2]R. Vahldieck, J. Bornemann, F. Arandt and D. Grauerholz, IEEE Trans. on MTT, MTT-31(1983), 65.[3]李嗣范等,中國科學,A輯,1982年,第9期,第857頁.[4]段趙東等,1985年全國微波會議論文集,(1985), 88. -
