矩形波導中沿E面均勻的介質柱散射特性分析
SCATTERING ANALYSIS OF E-PLANE UNIFORM DIELECTRIC POSTS IN RECTANGULAR WAVEGUIDES
-
摘要: 從關于介質極化電流的積分方程出發,用矩量法數值分析了矩形波導中沿E面均勻的任意截面形狀和數量的介質柱的散射特性。將介質區域分割成許多矩形小子域,使以矩形波導修正格林函數為核的積分方程能夠分區地進行解析處理,從而大大改善了計算精度和速度。計算中考慮了高次模的影響,既提高了計算精度,又提供了所有波型的散射信息。
-
關鍵詞:
- 矩形波導; 均勻介質柱散射; 極化電流積分方程; 格林函數
Abstract: Based on the polarization current integral equation with the modified Green s function as kernel, the scattering properties of the E-plane uniform dielectric posts in rectangular waveguides are numerically analyzed by moment method. These posts are of arbitrary in cross-stction and post-number. The calculation accuracy and speed are remarkably improved by segmentating the dielectric region into many small rectangular cells and applying local analytic integration. The higher-order modes are considered in calculation. It improves the computation accuracy and can provide the scattering information of all excited modes. -
J.Schwinger, Discontinuities in Waveguide-Notes on Lecture, New York, Gordon and Breach, 1969.[2]N.Marcuvitz, Waveguide Handbook, New York, McGraw-Hill, 1951.[3]Y.Levitan, P. G. Li, A. T. Perini, IEEE Trans, on MTT, MTT-31(1983), 806-812.[4]H.Auda, R. F. Harrington, IEEE Trans. on MTT, MTT-32(1984), 606-613.[5]J.N. Sahalos, E. Vafidis, IEEE Trans. on MTT, MTT-33(1985), 1165-1171.[6]G.Hsu, A. Auda, IEEE Trans. on MTT, MTT-34(1986), 883-891.[7]C.Araneta, IEEE Trans. on MTT, MTT-32(1984), 1328-1335. -
