多頻段共用的波紋圓錐喇叭
CORRUGATED CONICAL HORN FOR MULTI- FREQUENCY BAND USE
-
摘要: 本文闡述了波紋圓錐喇叭的多頻段工作原理,并介紹了一個至少能在4,6和11 GHz三個頻段共用的波紋圓錐喇叭。此喇叭在4,6 GHz頻段的交叉極化峰值優于-25dB,在11GHz頻段的幅度方向圖性能優良。理論和實踐表明,使用不止在一個工作區工作的波紋圓錐喇叭可以實現多頻段共用的饋源喇叭。
-
關鍵詞:
Abstract: The theory of corrugated conical horn operating at multi-frequency bands is described,. and a practical corrugated conical horn is constructed. It can operate at three frequency bands (4, 6, 11 GHz) at least. The cross poralization peak level is better than-25 dB at 4, 6 GHz frequency bands, and the amplitude pattern at 11 GHz frequency band is also very good It is shown theoratically and experimentally that the corrugated conical horn operating at multi-frequency bands is the best candidate for multi-frequency band feeds. -
Y. Takeichi, T. Hashmoto and F. Takeda, IEEE Trans. on MTT, MTT-19(1971), 947-50.[2]Z. Frank, Electronics Lett., 11(1975), 131-3.[3]陳木華,電子科學學刊, 8(1986), 64-7.[4]章日榮,趙再思,周康健,電子學報,1978年,第1期,第68-80頁.[5]陳木華,電子信息技術,1982年,第1期,第13-20頁.[6]C. Dragone, Bell Sys. Tech.J., 56(1977), 869-88.[7]C. Dragone, ibid., 56(1977), 835-67. -
