單軸介質加載鰭線的譜域?qū)Э狗?/h2>
A SPECTRAL-DOMAIN IMMITTANCE APPROACH FOR FIN LINES WITH UN1AX1ALLY AN1SOTROPIC SUBSTRATES
-
摘要: 本文通過分析和推導,將譜域?qū)Э狗〝U(kuò)展到單軸介質加載鰭線的特性分析。單軸介質的光軸方向既可平行又可垂直于介質分界面。通過對稱雙側鰭線的有效介電常數的數值計算,驗證了本文方法的正確性。
-
關鍵詞:
- 鰭線; 單軸各向異性; 譜域?qū)Э狗? 有效介電常數
Abstract: A characteristic analysis of the finlines with uniaxially anisotropic substrates using the spectral-domain immittance approach is presented. The optical axis of uniaxial substrate is either perpendicular or parallel to the substrate plane. This approach is tested to be correct, through the numerical calculation of the effective dielectric constant of a bilateral symmetry finlines. -
T. Itoh, IBEF. Trons, on MTT, MTT-28(1980)7, 733-736.[2]T. Itoh, W. Menzel. IEEE Trans. on AP, AP-29(1981)1, 63-68.[3]A.-A, T. K. Shalaby, A Kumar, IEEE Trans. on MTT, MTT-35(1987)4, 448-450.[4]R. M. Nelson, D. A. Rogers, A. G. Dassuncao, IEEE Trans. on AP, AP-38(1990)7, 973-981.[5]H.C. Chen著,梁昌洪等譯,電磁波理論無坐標方法,電子工業出版社,北京,1988年.[6]H-Y. Yang, N. G. Alexopoulos, IEEE Trans. on MTT, MTT-35(1987)1, 24 -29. -
