高速VLSI電路中傳輸線瞬態響應的靈敏度分析

毛軍發,  李征帆

毛軍發, 李征帆. 高速VLSI電路中傳輸線瞬態響應的靈敏度分析[J]. 電子與信息學報, 1997, 19(1): 72-76.
引用本文: 毛軍發, 李征帆. 高速VLSI電路中傳輸線瞬態響應的靈敏度分析[J]. 電子與信息學報, 1997, 19(1): 72-76.
Mao Junfa, Li Zhengfan. TRANSIENT SENSITIVITY ANALYSIS OF TRANSMISSION LINES IN HIGH-SPEED VLSI CIRCUITS[J]. Journal of Electronics & Information Technology, 1997, 19(1): 72-76.
Citation: Mao Junfa, Li Zhengfan. TRANSIENT SENSITIVITY ANALYSIS OF TRANSMISSION LINES IN HIGH-SPEED VLSI CIRCUITS[J]. Journal of Electronics & Information Technology, 1997, 19(1): 72-76.

高速VLSI電路中傳輸線瞬態響應的靈敏度分析

TRANSIENT SENSITIVITY ANALYSIS OF TRANSMISSION LINES IN HIGH-SPEED VLSI CIRCUITS

  • 摘要: 本文用特征法分析計算高速VLSI電路中傳輸線的瞬態響應相對于傳輸線參數和終端負載參數的靈敏度,從而為VLSI電路信號連接線的優化設計提供了一個有用工具。傳輸線的終端負載可以為非線性,傳輸?shù)男盘?hào)形狀可以任意,這是該方法區別于基于數值拉氏逆變換的靈敏度分析方法的最大特點。
    Abstract: The characteristics method is introduced to analyze the transient sensitivity of transimission lines in high-speed VLSI circuits with respect to the transmission line parameters or terminal parameters, supplying a useful tool for the optimization design of interconnects in VLSI circuits. The characteristics method differs from the existing sensitivity analysis method based on the numerical inverse Laplace Transform(NILT) technique mainly in that the characteristics method can deal with nonlinear terminals and arbitrary transmitted signals.
    • HTML全文
  • Djordjevic A R, Sarkar T K, Harrington R F. Time-domain response of multiconductor transmission[2]lines. Proc[J].IEEE.1987, 75(6):743-765[3]Mao J-F, Li Z-F. Analysis of the time response of multiconductor transmission lines with frequency-dependent losses by the method of convolution-characteristics. IEEE Trans, on MTT, 1992, MTT-40(4): 637-644.[4]Lum S, Nakhla M S, Zhang Q J. Sensitivity analysis of lossy coupled transmission lines. IEEE Trans on MTT, 1991, MTT-39(12): 2089-2099.[5]Zhang Q J, Lum S, Nakhla M S. Minimization of delay and crosstalk in high-speed VLSI interconnests. IEEE Trans, on MTT, 1992, MTT-40(7): 1555-1563.[6]Rahal-Arabi T, Suarez-Gattner R. A frequency-domain technique for the optimization of the electrical[7]performance of high speed multiconductor transmission-line networks in VLSI regimes. IEEE Trans. on CAS, part I, 1993, CAS-40(4): 262-296.[8]Branin Jr F H. Transient analysis of lossless transmission lines[J].Pros. IEEE.1967, 55(11):2012-2013[9]Orhanovic N, Tipathi V K, Wang P. Generalized method of characteristics for time domain simulation of multiconductor lossy transmission lines, IEEE ISCAS-S, U. S. A.: 1990, 2388-2391.
  • 加載中
計量
  • 文章訪問數:  2418
  • HTML全文瀏覽量:  132
  • PDF下載量:  462
  • 被引次數: 0
出版歷程
  • 收稿日期:  1995-01-03
  • 修回日期:  1996-03-19
  • 刊出日期:  1997-01-19
