多狀態反射計技術
MULTISTATE REPLECTOMETER
-
摘要: 本文討論了多狀態測試技術,并將它與多端口測試技術進行了比較,通過分析給出了多狀態測試時的功率關系。最后給出了一個工作在毫米波波段的多狀態反射計實例,所得結果是令人滿意的。
-
關鍵詞:
Abstract: A detail discussion on multistate technique and a comparison of it with the multiport technique are given. The relation between output powers and reflection of the device under test is shown. An experjmental millimeterwave multistate reflectometer is given and its measuring nesults are satisfactory. -
C. A Here, IEEE Trans. on IM, IM-21 (1972), 470.[2]G. F. Engen, ibid, IM-22(1973), 295.[3]G. P. Riblet, IEEE Trans. on MTT, MTT-29 (1981), 155.[4]L. C. Oldfield and J. P. Ide, Measurement of Complex Reflection Coefficient in,W-Band Measured Using a 4-port Reflecto-meter with Precision Waveguide Spacers, IEE Collcoquium on Advance in S-Parameter Measurement at Microwavelengths, in London, May 1983, pp.8/1-8/2.[5]E. J. Griffin, The Multistate reflectometer RSRE Memorandum No. 3625.[6]A. Jenkins, Seven Port Reflectometer, Ph. D. Thesis University College, London, 1982. -
