高階ADI-FDTD算法的數值色散分析
Analysis of the Numerical Dispersion of Higher Order ADI-FDTD
-
摘要: 該文給出高階交替方向隱時域優先差分(ADI-FDTD)算法，即在ADI-FDTD迭代公式的基礎上對時間的差分仍然采用二階中心差分格式，而對空間的差分則采用四階中心差分格式，并解析地證明了所給出的高階ADI-FDTD算法仍然滿足無條件穩定方程，同時對增長因子相位的分析，得到數值色散關系，最后對其數值色散誤差進行了分析，研究表明與普通ADI-FDTD相比，其色散誤差較小。
-
關鍵詞:
- 高階ADI-FDTD算法;數值色散
Abstract: In this paper, a new higher order Alternating Direction Implicit Finite-Difference Time-Domain (ADI-FDTD) formulation in particular, a second-order-in-time, fourth-order-in-space AD-FDTD method is presented for the first time. At the same time ,the unconditional stability of the higher order ADI-FDTD formulation is analytically proved. By analysis of the amplification factors, the numerical dispersion relation is derived. In addition, the numerical dispersion errors are investigated. Finally numerical results indicate that the higher order ADI-FDTD has s better accuracy compared to the ADI-FDTD method. -
Yee K S. Numerical solution of initial boundary value problem involving Maxwells equations in isotropic media [J]. IEEE Trans. on AP., 1966, 14(5): 302-307.[2]Krumpholz M, Katehi L P B. MRTD: New time-domain schemes based on multiresolution analysis [J].IEEE Trans. on Microwave Theory Tech.1996, 44(4):555-571[3]Liu Q H. The pseudospectral time-domain (PSTD) method: A new algorithm for solution of Maxwells equations [C] Proc. IEEE Antennas and Propag. Soc. Int. Symp., 1997, 1: 122-125.[4]Kondylis G D, De Flaviis F, Pottie G J, et al.. A memory-efficient[5]formulation of the finite-difference time-domain method for thesolution of Maxwells equations [J]. IEEE Trans[J].on Mcrowave Theor Tech.2001, 49(7):1310-1320[6]Zheng F, Chen Z, Zhang J. A finite-difference time-domain method without the Courant stability conditions [J].IEEE Microw Guided Wave Lett.1999, 9(11):441-443[7]Zheng F, Chen Z, Zhang J. Toward the development of a three-dimensional unconditionally stable finite-difference time-do[8]main method [J]. IEEE Trans[J].on Microwave Theory Tech.2000, 48(9):1550-1558[9]Namiki T. A new FDTD algorithm based on alternating-direction[10]implicit method [J]. IEEE Trans[J].on Microwave Theory Tech.1999, 47(10):2003-2007[11]Namiki T. 3-D ADI-FDTD method Unconditionally stable time-domain algorithm for solving full vector Maxwells equations [J].IEEE Trans. on Microwave Theory Tech.2000, 48(10):1743-1748[12]Namiki T, Ito K. Investigation of numerical errors of the two-[13]dimensional ADI-FDTD method [J]. IEEE Trans[J].on Microwave Theory Tech.2000, 48(11):1950-1956[14]Georgakopoulos S V, Birtcher C B, et al.. Higher-order finite-difference schemes for electromagnetic radiation, scattering, and penetration, part I: theory[J]. IEEE Trans.on AP, Magazine, 2002, 49(1): 134-142.[15]Sun G and Trueman C W. Analysis and numerical experiments on the numerical dispersion of two-dimensional ADI-FDTD [J].IEEE Antennas and Wireless Propagation Lett.2003, 2(7):78-81 -
