脈沖波形對其軸線能量傳播特性影響的研究
The study of axial energy decaying property influenced by pulse waveform
-
摘要: 在相同平面圓形輻射器條件下，對具有相同中心頻率的幾種典型脈沖，根據電磁場理論，給出了它們軸線能量傳播特性的解析計算公式和數字模擬結果。研究表明：當脈沖的上升時間小于有效脈沖寬度的1/20時，在脈沖傳播的慢衰減區，等腰梯形脈沖的傳播特性優于目前普遍應用的正弦脈沖。
-
關鍵詞:
- 脈沖波形; 傳播特性; 中心頻率
Abstract: With same circular radiating antenna, same center frequency pulse, the analytical and numerical results of axial energy of several typical waveform pulse are offered by electromagnetic theory. The results indicate: in the slow decaying area, the axial energy decaying property of isosceles trapezium electromagnetic wave pulse is better than that of sinusoidal electromagnetic waveform while its increasing time is shorter than one twentieth of the waveform width. -
［1］阮成禮,萬長華,電磁導彈的波形條件,科學通報,1990,36(10),738-741. ［2］R.W. Ziolkowski, D. K. Lewis, B. D. Cook, An experimental research for the localized wave packet, J. Acoust. Soc. Am. Suppl. 1, 1988, 84(1), 209-211. ［3］阮成禮,萬長華,袁乃昌,電磁導彈的初步實驗,電子科技大學學報,1992,21(1),92-97. ［4］Wen Keyi, Ruan Chengli, Lin Weigan, An unified theory of electromagnetic missiles generated by an arbitrary plane current source, Microwave and Optical Technology Letters, 1992, 5(7),337-340. ［5］H. M. Shen, T. T. Wu, The transverse energy pattern of an electromagnetic missile from a circular disk, Proc. SPIE, 1989, 1061, 321-324. -
