集成運放高Q模擬大電感
A HIGH Q LARGE INDUCTOR SIMULATION USING AN INTEGRATED OPERATIONAL AMPLIFIER
-
摘要: 本文提出一種用集成運算放大器作成的高Q模擬大電感(L=1H,Q=252)。較文獻[1]提出的用集成運算放大器制成的模擬電感(Q=15.8)的Q值提高近16倍。此外,文中還以L=100H,Q=100的模擬電感為例,敘述了這類高Q模擬電感的設計方法。
-
關鍵詞:
Abstract: In this article, a high Q large inductor simulation (L = 1H, Q = 252) using an integrated operational amplifier is described. Its Q value is 16 times as great as the inductor simulation (Q = 15.8) using an integrated operational amplifier deseribed in references[1, 2]. As an example, a design method of L = 100 H, Q = 100 inductor simulation using an mtegrated operational amplifier is also given. -
D. F. Berndt and S. C. Dutta Roy, IEEE J. on SC, SC-4(1969), 61.[2]S. C. Dutta Roy and V. Nagarajan, IEEE J. on SC, SC-5(1970, 95.[3]秦世才、王朝英,集成運算放大器應用原理,天津人民出版社,1979年,第189頁.[4]BP-6型聲頻頻譜記錄儀說明書,天津電子儀器廠. -
