回旋管模式選擇復合腔的設計分析
Design Analysis of a Mode Selective Cavity for Gyrotron Applications
-
摘要: 為了使一種新型復合開放式諧振腔能夠應用于毫米波回旋管器件，該文從工程設計的角度出發，分析這種腔結構中的公共壁增厚和軸向開漂移孔對腔中工作模式穩定性的影響，探討在實際工程設計中補償這種影響的手段。結果表明，合理增大復合腔外腔的半徑能夠有效實現工作模式的模式純度和相對穩定性。Abstract: The effects of thickening the cavity wall and constructing a pair of drift tube in a new complex cavity on the operating mode stability for engineering design are analyzed in this article. Some compensating methods for alleviating the effects are discussed, which shows that rationally increasing the radius of the outer cavity in the complex cavity may effectively realize high purity and stability of the operating mode.
-
Granatstein V L, Levush B, Danly B G, Park R K. A quarter century of research and development. IEEE Trans. Plasma Sci. 1997, 25(6): 1322-1335.[2]Jiang L. Theory for cylindrical, open ended, complex cavities supporting all TE0n modes: Gyrotron application. IEE Proceedings-H, 1991, 138(4): 297-306.[3]Guo H, Wu D S, Liu G, Miao Y H, Qian S Z, Qin W Z. Special complex open-cavity and low-magnetic-field high-power gyrotron[J].IEEE Trans. Plasma Sci.1990, 18(3):326-333[4]郭煒, 羅積潤. 一種回旋管新型復合開放式諧振腔的性能分析[J].電子與信息學報.2006, 28(4):765-768瀏覽 -
