開關電容V/Q變換器及其在接地阻抗模擬中的應用
SWITCHING CAPACITANCE V/Q TRANSVERTER AND ITS APPLICATION IN GROUNDED IMPEDANCE SIMULATION
-
摘要: 文中提出一個V/Q變換的廣義跨導概念,并應用在開關電容阻抗模擬中。使用V/Q變換器,可以用電壓傳遞函數實現所希望的阻抗函數。由此概念出發,分別導出了前差FD,后差BD和雙線性S/Z變換的三種接地開關電容頻變負阻SC-FDNR電路。如果所選用的電壓傳遞函數電路對雜散電容不靈敏,那么實現的模擬阻抗電路對雜散電容也是不靈敏的。作為文中的一個例子,用FD-FDNR電路組成一個諧振回路,實驗表明其頻響特性與理論分析相一致。Abstract: A concept of general transconductance of V/Q (voltage/charge) transformation i.. proposed, and applied to the simulation of switching capacitance impedance. By Using V/Q transverter, the expected impedance function can be implemented by means of volrage transfer function. Starting from this concept, the switched capacitor-FDNR (frequency dependent negative resistor) circuits of three kinds of S/Z transformation (i.e. forward differential SfZ transformation, backward differential S/Z transformation, bilinear S/Z transformation) are respectively deduced. If the selected voltage transfer function circuit is not sensitive to stray capacitance, then the implemented simulation impedance circuit is also not sensitive to stray capacitance. As an example, a resonant loop is composed of forward differential FDNR circuit. The experiments show that the characteristics of its frequency response coincide with the theoretical analysis.
-
R. J. Hosticka, G. S. Moschytz, Electron Lett., 14(1978)24,788-789.[2]G. C. Temes, M. Jahanbegloo, Electron Lett., 15(1979)3,[3]-88.[4]S. M. Farugue, J. Vlach, T.R.Viswanathan, IEE Proc., 128(1981)4, Pt. G, 227-229.[5]T. R. Visawanthan ,et al., IEEE Trans on CAS, CAS-27(1980)6, 502-508.[6]S. M. Farugue, et al., FDNR Switched-Capacitor filters Insensitive to Parasitic a Capacitances, ISCAS'82, pp. 440-442.[7]P. E. Fleischer, et al., Electron Lett., 17(1981)24, 929-931. -
