InGaAsP/InP雙異質結發光管中的深能級
DEEP LEVEL IN InGaAsP/InP DH LED
-
摘要: 本文用DLTS譜儀研究了SiO2限制的InGaAsP/InP雙異質結發光管中的深能級。結果表明:只有在p-n結位于p-InP/n-InGaAsP界面處的個別器件中,有△E=0.24eV的多子陷阱。Abstract: The deep level in InGaAsP/InP DH LED have been studied by DLTS method. The results show that when the p-n junction located in the interface of the p-InP/n-In GaAsP, there is deep level in some InGaAsP/InP DH LED. The activation energy △E is 0.24eV.
-
高季林,半導體學報,6(1985), 245.[2]Yoichi Sasai, et al., Jpn. J. Appl Phys., 18(1979)7. 1415.[3]M. Levinson, et al., Appl Phys. Lett., 42(1983)7,605.[4]水海龍等,發光與顯示,1982年,第3期,第72頁.[5]邵永富等,半導體學報, 3(1982),215.[6]楊易等,電于科學學刊, 7(1985)5,395-400.[7]吳冠群等,通信學報,4(1982),88.[8]張桂成等,發光與顯示,1982年,第2期,第65頁.[9]J. Shirafuzi, et al., J.Appl. Phys., 52(1981), 4705. -
