基于可編程跨導運算放大器POTA低通有源濾波器設計
Lowpass Active Filter Design Based on Programmable Operational Transconductance Amplifiers(POTA)
-
摘要: 該文給出了基于可編程跨導運算放大器(POTA)的有源濾波器設計方法，能在一定范圍內實現跨導值程控調節, 提高調節精度和準確度。并且利用Jacobi法求解相似對角形矩陣，避免解高次方程的難題。所設計的有源濾波電路不易受分布電容的影響，穩定性好、靈敏度低。本文給出了設計實例，顯示了該方法的優點。Abstract: In this paper, a method of active filter design based on Programmable Operational Transconductance Amplifiers(POTA) is given. The transconductance is adjusted by software in order to improve accuracy. The design procedure is based on Jacobi method and similar diagonal matrix. The difficulties of finding the roots of high order polynomial can be avoided by using Jacobi method. Active filter circuit is composed of POTA and ground capacitors. It has the characteristics of high stability and low sensitivities. A design example is given and the simulated results show that the given method is suitable for continuous time active filter design.
-
Analog Devices Inc.,1-/2-/4- Channel Digital Potentiometers,Data Sheet.2002.[2]Oziel S, Szczepanski S, Schaumann R. Design of highly linear tunable CMOS OTA, 2002. ISCAS 2002. IEEE International Symposium on, Circuits and Systems, May 26-29, 2002, Vol. 3: 731-734.[3]J．H．威爾金森[英]著，石鐘慈, 登健新譯. 代數特征值問題.北京：科學出版社，2001: 275-354.[4]Hayahara E, Enomoto M. Deriving technique of equivalent forms from general filter circuits and its application[J].IEEE Trans. on Circuits and Systems.1999, 46(9):1037-1041 -
