B樣條函數在二維導體橫截面輪廓成象中的應用
APPLICATION OF B-SPLINE IN RECONSTRUCTION OF 2-D CONDUCTOR CROSS-SECTION
-
摘要: 本文將B樣條函數應用于根據多入射方向下的后散射場對二維導體柱橫截面形狀的反演,并將整個反演過程轉化為兩次非線性優化過程。由于兩次優化的目標函數的導數都是可求得的,因此采用基于梯度的優化算法,如Broyden-Fletcher-Goldfard-Shanno變尺度算法(簡稱BFGS方法)。第一次優化最佳的等效圓柱的半徑和深度,然后在第二次優化過程中再進一步優化導體柱橫截面的控制節點以得到反演的形狀。最后,以數值結果驗證了該方法的有效性,并討論了該方法的抗噪聲性能。
-
關鍵詞:
- B樣條函數; Frechet微分; BFGS方法; 輪廓成象
Abstract: B-spline is applied to the reconstruction of 2-D conductor cross-section via backscat-tered field in near region illuminated by plane waves with different incident directions. The whole inverse problem may be viewed as a two-stage optimal procedure, and the optimal algorithm based on gradient, such as BFGS algorithm, is adopted as the gradient of the objective functions which may be derived by using Frechet differential. In the first step, the position and the radius of optimal circular cylinder are obtained, then in the second step, with above results as its initial values, the shape of 2-D cylinder can be reconstructed. The robustness of the proposed method is tested using different numerical results, and the effects of noise are discussed. -
葛德彪.電磁逆散射原理.西安:西北電訊工程學院出版社,1987, 109-153.[2]Colton D, Monk P. SIAM J. Appl. Math., 1985, 45(6): 1039-1053.[3]Chien-Ching Chiu, Yean-Woei Kiang. Journal of Electromagnetic waves and Applications, 1992[4]10): 1413-1431.[5]Otto G P, Weng Cho Chew, et al. IEEE Trans. on MTT, 1994, MTT-42(1): 137-141.[6]應道寧,等.計算機繪圖.杭州:浙江大學出版社,1990,186-193.[7]楊儒貴,等.電磁理論.西安:西安交通大學出版社,1991,125-126.[8]陳開周.最優化計算方法.西安:西北電訊工程學院出版社,1985,87-98. -
