短溝DMOS閾值電壓模型
A Threshold Voltage Model of the Short Channel DMOS
-
摘要: 該文提出了短溝DMOS閾值電壓模型?；跍系绤^(qū)耗盡電荷的二維分布,計算溝道區中耗盡電荷總量,由此給出短溝DMOS閾值電壓模型的計算式。該模型的解析解與二維仿真器MEDICI的數值解吻合。分析表明,DMOS溝道長度小于0.80m,就應考慮短溝效應。
-
關鍵詞:
- DMOS; 閾值電壓; 短溝效應
Abstract: A threshold voltage model of the short channel DMOS (Double-Diffusion Metal-Oxide- Semiconductor) is proposed. Based on the 2-D distribution of channel depletion charge, the channel depletion charge is calculated and the mathematical expression of the threshold voltage model of the short channel DMOS is obtained. The results of the model agree well with those of the 2-D simulator MEDICI. The analysis shows that the effect of short channel should be considered when the channel length is less than 0.80m. -
李澤宏,李肇基,張波等.非均勻溝道MOS輻照正空間電荷遷移率模型.物理學報,2004,53(2):561-565.[2]李澤宏,張波,李肇基等.DMOS閾值電壓二維模型.半導體學報,2004,25(6):715-719.[3]Kasley K L, Oleszek G M, Zigadlo J P. A model for the lateral junction contour of double-diffused Gaussian profiles[J].IEEE Trans. on Electron Devices.1984, 31 (7):1341-[4]Baliga B J. Power Semiconductor Devices. Boston: PWS Publishing Co., 1996:265 - 278.[5]江月明.超級靈巧電源技術進入納米領域.中國集成電路,2003,3(6):56-59.[6]Maneesha, Subhasis Haldar, Manoj K. Khanna. Analytical theory of two-dimensional charge sheet model for short channel MOSFETs under non-linear charge control. Solid State Electronics, 1995, 38(11): 197- 185.[7]Chang-Hoon Choi, Chidambaram P R, Khamankar R, Machala C F, et al.. Dopant profile and gate geometric effects on polysilicon gate depletion in scaled MOS, IEEE Trans[J].on Electron Devices.2002, 49(7):1227-[8]AVANT. Medici 4.1 Users Manual, 1994. -
