壓控振蕩器的計算機輔助設計
COMPUTER AIDED DESIGN FOR VOLTAGE CONTROL OSCILLATOR
-
摘要: 本文從準正弦的方法導出了變?nèi)荻O管調諧的耿氏二極管壓控振蕩器的電路方程。對非線性元件作了專門的處理,得到了一個通用的計算機程序,這個程序可以計算小信號和大信號的靜態調制特性,也可以計算動態特性和各參量對過渡過程的影響。
-
關鍵詞:
Abstract: A set of eqaations for varactor tuning Grunn Diode Oscillator is derived by quasi-sinusoidal method. By special treatment of the nonlinear element, a program is obtained. With this program the small signal and large signal statistic tuning performance, dyna-mic behavior and transient response can be calculated. -
VCO Technology, Final Report, Feb. 1979, EPL, University of Michigan.[2]D. F. Peterson, IEEE Trans. on MTT, MTT-23(1980), 110.[7]L. Gustafsson et al., IEEE Trans. on MTT, MTT-20(1972), 402.[8]宋文淼,微波電路的計算機輔助設計,中國科學院電子學研究所1982年科學技術報告會. -
