示波管偏轉系統上升時間計算模型
THE CULCULATING MODEL OF THE RISE-TIME FOR DEFLECTION SYSTEM OF OSCILLOTRONS
-
摘要: 本文提出了示波管偏轉系統高頻性能分析新方法。通過分析電子在偏轉系統內的渡越時間差模型,導出偏轉系統在單位階躍電壓函數作用下,電子束掃描軌跡方程及上升時間的計算。
-
關鍵詞:
- 示波管; 渡越時間差; 單位階躍電壓; 電子束掃描軌跡; 上升時間
Abstract: A new method of analysing the high-frequency behaviour of the deflection system of oscillotrons is described. By analysing the tr ansit-time-different model of the deflection system of oscillotrons under unit-step function voltage, either the sweep trace of the electron beam or calculating formulae of the rise time can be derived. -
Hans E. Hollman, Proc. IRE, 38(1950), p. 32.[2]陳威森,染料激光的能量測量及自動記錄,中國激光,6(1979)1,42.[3]М.Я.暮良洛夫,電子束器件,國防工業出版社,1959年,p. 83. -
