1-18GHz微帶巴倫雙平衡混頻器
A 1-18GHz MICROSTRIP BALUN DOUBLE BALANCED MIXER
-
摘要: 本文介紹了一種微帶巴倫多倍頻程微波集成雙平衡混頻器。它是由寬帶微帶巴倫和二極管電橋組成。這種微帶巴倫雙平衡混頻器顯示了良好的噪聲特性和隔離特性。在1-18GHz工作頻率范圍內,最大雙邊帶噪聲系數為8.7dB,平均雙邊帶噪聲系數約6dB;本振端一信號端、本振端一中頻端隔離度均大于15dB。
-
關鍵詞:
- 寬帶混頻器; 雙平衡混頻器; 微帶巴倫
Abstract: A multi-octave microstrip balun double balanced mixer has been developed. This mixer which is consisted of a broad-band balun and a diode ring exhibits extremely encouraging performance. Within the multi-octave bandwidth from 1 to 18 GHz, the average DSB noise figure is 6 dB, and the maximum DSB noise figure is 8.7 dB, and both LO-RF and LO-IF isolations are more than 15 dB. -
U. S. Patent, 3,652,941, Feb. 1970.[2]M. A. Smith.[J].A. M. Pavio, IEEE IntI Microwave Symp. Digest, St. Louis, U. S. A.1985,:-[3]王宗欣,電子技術,，1980年,第4期,第10-13頁.[4]王新,鄧少范,寬帶雙面微帶巴倫線的設計,1985年全國微波會議論文,西安,1985年.[5]吳萬春等編,微波網絡及其應用,國防工業出版社,1980年,251. -
