一種小波分解濾波器高速實現結構
AN IMPLEMENTATION OF WAVELET DECOMPOSITION FILTER BASED ON SYSTOLIC STRUCTURE
-
摘要: 近年來,小波變換得到了廣泛的應用,快速塔式分解算法是它應用的一個有利工具,其地位相當于FFT之于Fourier分析,因此DWT的快速硬件實現變成了其應用的一個重要問題,本文通過將并行systolic FIR濾波器結構引入小波分解濾波器的設計,得到了一種小波分解濾波器的實現結構。該結構由于應用了systolic技術及采用并行結構,除了可以提高運算速度外,還可以提高系統的數據吞吐率以及降低系統功耗。
-
關鍵詞:
- 小波分解; Systolic結構; 并行實現
Abstract: In recent years, the wavelet transform has been widely used in many fields. The fast tower-type algorithm is an efficient tool. Its importance is just like that of FFT in the Fourier analysis. Therefore the hardware implementation of the DWT is an important problem in its applications. With the introduction of the parallel systolic FIR filter structure to the design of the wavelet decomposition filter, an implementation structure of wavelet decomposition filter is presented in this paper. As being parallel and systolic, the structure can increase data throughput and reduce power consumption of the system as well as enhance operation speed. -
水鵬朗,廣義內插小波和遞歸內插小波理論及應用的研究,[博士論文],西安,西安電子科技大學,1998[2]Shang Yong.[J].Wu Shunjun, Design of parallel adaptive FIR filters, IEEE APCCAS98, Chiangmai,Thailand.1998,:-[3]P.P. Vaidyanathan, Multirate digital filters, filter banks, polyphase networks, and applications,A tutorial. Proc. IEEE, 1990, 78(1), 56-93.[4]尚勇,吳順君,一種新的FIR濾波器脈動實現結構,電子學報已錄用.[5]貢三元,VLSI陣列處理,南京,東南大學出版社,1992,132-193.[6]S.K.Rao, T. Kailath, Regular iterative algorithms and their implementation on processor arrays.Proc. IEEE, 1988, 76(3), 259-269. -
