數域處理的二相編碼信號旁瓣抑制技術研究
Study on range sidelobe suppression techniques of biphase coded signals based on the processing in frequency domain
-
摘要: 該文從二相編碼信號的頻譜結構分析入手,采用頻域數字處理方法,研究了二相編碼長碼雷達信號距離旁瓣頻域抑制加權技術,提出一種適用于各種碼長不同碼序列的編碼信號旁瓣抑制濾波器(SSF)頻域設計方法。并以127位二相編碼信號為例,對SSF處理的性能進行仿真分析和實驗測試。當fd=0時,仿真與實測結果的主副比分別達到50dB和43dB。這表明采用這種方法所設計的二相碼信號SSF可以應用于現代雷達系統,并得到滿意的性能指標。
-
關鍵詞:
- 二相編碼信號; 旁瓣抑制; 主副比; FFT
Abstract: This paper studies the range sidelobe suppression techniques for long-biphase coded signals by applying digital processing in Frequency domain. By analyzing the spectrum characteristics, a design method in frequency domain for Sidelobe Suppression Filters (SSF), which is suitable for various code lengths and different code sequences, is presented. As an example, computer simulations and experimental results of 127-bit biphase coded signals processed by the SSF are also given. When fd = 0, RMS are achieved to 50dB and 43dB for simulations and experiments respectively. These show that biphase coded signal SSF designed by this method can be applied in modern radar systems, and the satisfactory performance are achieved. -
林茂庸,雷達信號理論,北京,國防工業出版社,1984,153-178.[2]Chen Xiaohua, J. Oksman, A new algorithm to optimize barker code sidelobe suppression filters,IEEE Trans. on AES, 1990, 29(4), 673-677.[3]M.N. Cohen, J. M. Baden, P. E. Cohen, Biphase codes with minimum peak sidelobes, Proc. of IEEE National Radar Conference, 1989, Dallas, Texas, 62-66.[4]劉強,雷達脈壓信號優化設計及數字處理研究,[博士學位論文],成都,電子科技大學,1993. -
