瞬態電磁脈沖在地下目標探測中的應用
APPLICATION OF TRANSIENT ELECTROMAGNETIC PULSE IN DETECTING SUBSURFACE TARGETS
-
摘要: 本文描述了納秒電磁脈沖在探測地下目標中的基本方案;研制了一種高質量行波天線。作者采用的是三層結構的扇形天線,其輻射效率高,行波特性好。終端采用快速、高分辨率的圖形顯示系統,對埋地深度在1m左右的金屬管道,能清晰的顯示,并打印出目標特性。整個裝置與國內外同類裝置相比,分辨率高,終端處理時間短,符合工程需要。Abstract: A basic scheme for detecting subsurface targets with EM pulse of nanoseconds and an especially developed travelling-wave antenna of high quality are described. The antenna is a sort of sector antenna with structure of three layers, which possesses higher radiation efficiency and better travelling-wave properties. A fine resolution graphic system and a high speed display are employed in terminal processing. Metal pipes burried about 1m under the earth can be detected and clearly displayed. High resolution and burried about lm under short processing time of the system, compared with other similar devices make it suitable for engineering use.
-
D. J. Daniels et al., Introduction to Subsurface Radar, Special Issue on Subsurface Radar, IEE Proc.-F, August, (1988), 278-320.[2]J. D. Young, R. Caldecott; Underground Pipe Detector, U. S. Patent 4062010, (1977).[3][3][4]L. C. Chan, D. L. Moffatt, L. Peter, Proe. IEEE, 67(1979) 7, 991-1000.[5]潘仲英等,電波科學學報,3(1988)3/4,68-76.[6]Keiichi Ueno et al., An Underground Object Imagine System with Computerized Reconstruction NTT Elec. Com. Lab., 9-11, Midori-Cho, 3-Chome Musashino-shi, Tokyo 180 Japan, (1986).[7]Teruo Usami et al., Detection of the Underground Pipes by Synthetic Aperture Techniques, The Trans. of the IECE of Japan, 69E(1986) 4,491-493.[8]廖春林,章錫元,無載脈沖地下目標探地系統的實現與實驗,1986年全國電波年會論文,北京,第351-353頁.[9]聶在平,謝俊,用瞬變電磁脈沖進行地下目標探測,電子科技大學技術報告,成都,1985年12月.[10]T. T. Wu, R. W. P. King, IEEE Trans. on AP, AP-12 (1965)，，369-374. -
