非線性平板介質波導傳輸特性的網絡分析
THE ANALYSIS OF NONLINEAR PLATE DIELECTRIC WAVEGUIDE WITH NETWORK METHOD
-
摘要: 本文提出了分析包含非線性介質的層狀介質波導特性的等效傳輸線方法。通過把線性和非線性介質分別用等效傳輸線表示,從而把非線性介質這一復雜的電磁場問題等價成一個電路問題求解。其本征方程可以利用橫向諧振原理得到。本文最后分析了層狀介質波導包含飽和和非飽和非線性介質時TE模的傳播功率與歸一化傳播常數之間的關系。所獲得的結果與有關文獻符合得相當好。
-
關鍵詞:
- 介質波導; 非線性; 傳輸線
Abstract: This paper presents a so called equivalent transmission line method for the analysis of multilayer dielectric waveguide involving nonlinear dielectric. By introducing the equivalent transmission line model of nonlinear dielectric and linear dielectric, the electromagnetic field problem about the nonlinear dielectric waveguide can be equivalent to a circuit problem. The eigen-equation governing the nonlinear dielectric waveguide can be obtained by using the transversal resonance technique. Finally, the multilayer dielectric waveguides involving saturable or non-saturable nonlinear dielectric are simulated, and the relations between the propagating power of TE mode and the normalized wavenumber are given. The results obtained are in good agreement with that in the references. -
kazuhiko Ogusu. IEEE Trans. on MTT, 1989. MTT-37(6): 941-945.[2]Boardman D. Eean Y. IEEE J. of QE, 1986. QE-22(2): 319-324.[3]Stegman et al. IEEE J. of QE, 1986, QE-22(6): 977-981.[4]Biehlig W, et al. IEEE J. of QE, 1991, QE-28(7): 1643-1646.[5]Jianguo Ma. lnt[J].J. of Infrared and Millimeter Waves.1993, 14(8):1701-1715[6]Kazuhiko Ogusu. Optical Communications, 1987, 64(5): 425-430.[7]Mihalache D, Mazilu D. IEE Proc.-J. Optoelectronics, 1991, 138(6):[8]5-372. -
