設計晶體調頻振蕩器頻偏的新公式
NEW FORMULAS FOR DESIGNING FREQUENCY DEVIATION OF CRYSTAL FM OSCILLATOR
-
摘要: 本文在分析晶體調頻振蕩器振蕩頻率的基礎上,得出了晶體調頻振蕩器頻偏的一般表示式、最佳負載條件下的頻偏設計公式和調制級有電流串聯負反饋時的頻偏設計關系式。
-
關鍵詞:
Abstract: On the basis of analyzing the oscillatory frequency of crystal oscillator, the general expression of the frequency deviation of crystal frequency-modulation oscillator is de-rived. The design formulas of the frequency deviation under optimum load condition and under condition of the modulating stage with series negative current feedback are also given. -
P. W. Wood, Electronics, 32(1959), 5, 64.[2]R. E. Sentz and R. A. Bartkowlak, Feedback Amplifiers and Oscillators, Holt, Rinehart and Wiston, Inc., New York, 1968, pp. 137-139.[3]清華大學通信教研組,高頻電路,人民郵電出飯社,1983, p. 508.[4]M. E. Frerking, Crystal Oscillator Design and Temperature Compensation, Litton Educational Publishing Inc., New York, 1978, pp. 20-48.[5]謝嘉奎,電子線路(非線性部分),高等教育出版社,1984,pp. 229-246. -
