用復射線展開法分析目標的雷達截面
ANALYSIS OF TARGET RCS BY COMPLEX RAY EXPANSION
-
摘要: 本文根據復射線分析和場的高斯波束展開,提出了一種計算復雜目標電磁散射特性的簡便方法。由于復射線法不受目標形狀的限制,因此該方法可用于任意形狀的目標。本文以矩形進氣道為例,進行了雷達截面分析計算,并將計算值與測試值比較,結果表明這種方法是可行的。
-
關鍵詞:
- 雷達截面; 電磁散射; 復射線分析; 平面波展開
Abstract: Based on the complex ray method and source expansion with a set of Gaussian beams, a new method for analysis and calculation of radar cross-section (RCS) of a complex target is presented. This method can be used for arbitrary shaped object, because complex ray analysis is not limited by the shape of object. A hollow rectangular pipe as a model of an air intake is investigated. The effectivenejs of this method can be proved from the comparison of calculated and measured results. -
L. B. Felsen, J. Opt. So c. Am. A; 3(1986)4, 486-496.[2]阮穎錚,通信學報,8(1987 )4,49-57.[3]阮穎錚,成都電訊工程學院學報,16(1987)1,28-33.[4]A.J. Bogush, Jr., R. E. Elkins, IEEE Trans. on AP, AP-34(1986)2, 228-243.[5]M.J. Bastiaans, Optik, 57(1980)1, 95-102.[6]Y.Z. Ruan, L. B. Felsen, J. Opt. Soc. Am. A, 3(1986)4, 566-579.[7][7][8]H. R. Wit t, E. L. Price, Proc. IEE, 115(1968)1, 94-100.[9]郭榮偉,舒永澤,隱身式進氣道機理與應用研究(1),南京航空學院內部報告,1987年. -
