L波段相對論速調管束流實驗研究
STUDY ON CURRENT OF L-BAND RELATIVISTIC KLYSTRON AMPLIFIERS
-
摘要: 介紹在L波段強流相對論速調管研究中,強流相對論短脈沖空心電子束的產生、傳輸、束流調制及其診斷等方面的初步實驗研究情況。在直線感應加速器上,利用66mm、壁厚3mm的石墨空心陰極,加上約5kGs的準直流引導磁場,引出了約500kV、4.5kA、脈寬100ns、54.5mm、厚度4.5mm的空心電子束。注入500kW的微波調制,束流經過輸入腔后,得到了約6％的最大基波電流調制深度,經過中間腔后,得到了約23％的基波電流調制深度。Abstract: Emission, translation, modulation and diagnosis of short pulse intense relativistic hollow electron beams (IREBs) of a L-band relativistic klystron amplifier are described in this paper. The hollow electron beams about 500kV, 4.5kA, diameter 54.5mm, thickness 4.5mm are obtained, and 6% of beam current modulation is gotten after the electron beams get through the input cavity gap, as well as 23% of beam current modulation is gotten after the electron beams get through the idler cavity gap.
-
Friedman M,Krall J, et al. Externally modulated intense relativistic electron beams. J.Appl.Phys. 1988,64(7): 3353-3379.[2]Friedman M, Serlin V. Present and development of high power RKA. SPIE Intense microwave and particle beams 1992(1629):1-7.[3]Fazio M V, Haynes W B, Carlsten B E. A 500MW lp,s pulse length high current relativistic klystron[J].IEEE Trans. on Plasma Science.1994, 22(5):740-749[4]黃華,王平山,甘延青,等.L波段相對論速調管放大器初步研究.強激光與粒子束,1998, 10(1): 135-139.[5]R.B.米勒著,劉錫三,等譯.強流帶電粒子束物理學導論.北京原子能出版社,1990: 21-25.[6]吳中發,王玉芝,黃益新.脈沖磁場中波導渦流影響的數值模擬.強激光與粒子束,1997, 9(2): 265-270.[7]謝家麟,趙永祥著,速調管群聚理論,北京:科學技術出版社,1960, 82-124.[8]黃華,王平山,甘延青,等.L波段相對論速調管輸入腔研究.強激光與粒子束,1997, 9(4): 573-577. -
