大斜視SAR成像的一種新的二維可分離處理方法
A New Two-Dimension-Separated Approach to High Squint SAR Processing
-
摘要: 大斜視角下SAR信號的特點表現為大的距離走動和小的距離彎曲，這使得采用橫距域距離走動校正和二維可分離成像方法成為可能,但方位場景較大時要考慮方位向聚焦深度的限制。該文采用非線性調頻變標的方法補償方位向調頻率隨目標橫距的變化，得到了良好的結果。
-
關鍵詞:
- 大斜視SAR成像; 方位向聚焦深度; 非線性調頻變標
Abstract: The high squint SAR signal features large range walk and small range curvature, which enable the raw data be compressed in range and azimuth separately. But in case of large azimuth scene size , complex algorithms must be used to cope with the constraint of the focus depth. In this paper a new two-dimension-separated method is presented to compensate the azimuth-dependent chirp rate using a non-linear chirp scaling operation. Finally simulation results are presented to verify the method. -
Jin M Y,Wu C.A SAR correlation alorithm which accomodates large range migration.IEEE Trans.on GRS,1984,22(6):592-597.[2]Wong F H.[J].Gumming IG. Error sensitivities of a secondary rangecompression algorithm for processing squinted satellite SAR data.Proc.IGARSS89, Vancouver.1989,:-Chang C Y.[J].Jin M, Curlander J C. Squint mode SAR processingalgorithms. Proc.IGARSS89, Vancouver.1989,:-[3]Smith A M. A new approach to range-Doppler SAR processing[J].Int. J. Remote Sensing.1991,12(2):235-[4]Runge H, Bamler R. Verfahren zur korrektur von range migrationbei einer bilderzeugung bei synthetischem apertur radar. DLRpatent application, July 8, 1991.[5]Davidson G W, Gumming I G, Ito M R. A chirp scaling approachfor processing squint mode SAR data. IEEE Trans, on AES, 1996,32(1): 121 - 133.[6]Jakowatz C V, et al. Spotlight-Mode Synthetic Aperture Radar: A Signal Processing Approach, Boston: Kluwer Academic Publishers, 1996: chapter 3.[7]Tat Soon Yeo, Ngee Leng Tan, Cheng Bo Zhang, Yi Hui Lu. A new subaperture approach to high squit SAR processing.IEEE Trans.on GRS,2001,39(5):954-968.[8]徐永健,婁曉光,王貞松.拉格朗日乘子法在機載SAR成像系統降采樣濾波器設計中的應用.電子學報,2000,28(12):11-14. -
